Automatic Robot Palletizer
US$ 75,000 - 200,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New, New
Application:
Other, palletizing, Bag palletizing
Packaging Type:
Cartons, Cans, Bags
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Application
Other, palletizing, Bag palletizing
Packaging Type
Cartons, Cans, Bags
Packaging Material
Wood
Automatic Grade
Other, Automatic, Automatic
Driven Type
Electric
Voltage
Can be adjusted according to actual situation
Power
Can be adjusted according to actual situation
Place of Origin
Shanghai, China
Brand Name
Daesum
Model Number
MP-R-11A
Dimension(L*W*H)
Can be adjusted according to actual situation
Certification
ISO
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
robot palletizer1.Using Japan robot
2.Suitable for bags,barrels,boxes
3.high quality and reasonable price
4.Easy Operat
Automatic Robot Palletizer
Suitable for bags, drums/ barrels and boxes.
We are a professional manufacturer of packaging machinery in China, integrating the R&D, manufacture, distribution and after-sales service since 2003. With nearly two decades of development, we have been congregating talents of machine manufacturing industry, and kept ahead in the research and development.
And for the robot palletizer. Fuji Yusoki Kogyo Co., Ltd from Japan is our cooperator. So our palletizer adopts Japanese robot, To ensure the quality of our products.
Palletizer basic structure parts:
| No. | Parts' name | Origin |
| 1 | conformal Conveyor | Daesum |
| 2 | Infeed Conveyor | Daesum |
| 3 | slow speed hand gripper | Daesum |
| 4 | Robot | Japan Fuji |
| 5 | Base for Robot | Daesum |
| 6 | Palletizing comveyor | Daesum |
| 7 | Safety Fence | Daesum |
| 8 | Control Panel for Conveyor line | Daesum |
| 9 | Power Supply (Transformer) | Daesum |
|
TECHNICAL SPECIFICATIONS |
|||
Handling capacity |
200 kg (including hand) |
Operation space |
2300 x 1500 mm(On request) |
Speed |
1600 cycles per hour |
Robot rotation |
330 o |
Degree of freedom |
4 axces |
Hand rotation |
330 o |
Hand gripper |
Clamp, Fork, Vacuum, Customized |
Power |
4-6 Kw |
Memory |
30 programmable patterns (optionally up to 400) |
Weight |
About 2380 kg |
Machine Details:
Double Lines:
Working process:
1.
2.
3.
4.
The control boxes:
After-sales service
a. Our company offer one year warranty electronic measurement equipment product. Warranty period, Because of the quality problem, the system can't normal use, our company responsible for the free services, until the user normal use; If because of the users or Warranty period, our company responsible for the paid service, long-term preferential provide spare parts, ensure user normal use.
b. In order to guarantee the normal operation of the equipment are in use and timely maintenance, our company pays great attention to the user operation and maintenance personnel training, equipment at the user's site debugging acceptance, our company site technical service personnel will be training operation at first; The other in the factory for users free training 2 ~ 3 maintenance person.
c. Equipment malfunction in use process , our company once received the maintenance demand information, ensure the timely response within 48 hours and send technical service staff rushed to the scene promptly, to solve problems.
