Applications of baler clothing machines:
This series baler is widely used to press and pack jumbo bags, normal woven bags, and cloth, etc.
The four corners equipped with a limit pulley, it can reduce press plate skewing when working.
Features of baler clothing machines:
Hydraulic system: through the manual valve, the cylinder piston drives the press plate up and down, and complete the compression- reset whole process;
Equipped with automatic over pressure overflow device, to ensure the machine work normally and safely under the specified pressure.
This series of balers, are of reasonable structure, convenient operation, strong packing, low noise, low power consumption and high efficiency.
Based on user’s requirements, we can install the automatically pushing device to reduce labor intensity, and ensure more convenient operation.
Technical details of baler clothing machines:
Model |
Y-20 |
Y-30 |
Y-40 |
|
Bale size (W×L×H) (mm) |
1200×750×650
|
1200×800×650 |
1200×850×700 |
Power (kw) |
2.2 |
3 |
4 |
Pressure (Mpa) |
6-8 |
8-12 |
8-15 |
Travel distance (mm) |
800 |
800 |
900 |
Control type |
Manual |
Manual |
Manual |
Oil cylinder diameter (mm) |
¢125 |
¢125 |
¢140 |
Dimension(m) |
1.6×0.85×2.25 |
1.6×0.85×2.25 |
1.6×0.9×2.8 |
Weight (KG) |
1500 |
1600 |
1800 |
Now Contact Yilia to get best price immediately via Skype: yilia_9 or mobile: 0086 15890080350.
