door aluminium and window aluminium profile
We are the biggest aluminium extrusion profile manufactruer in Jiangsu provinde of China.
Produce as your design.
1·Material :6000 series. other grades up to customers requirement
2·Temper: T3 - T8
3·Surface finish :
1)mill-finish
2) Anodizing :such as silver anodizing ,mat anodizing ,gold anodizing,
3) powder coated
4) sand spray
4·Length : As customer's any requirement
5·Packing :Film paper,cartons, Kraft paper, Plastic woven belt, Hot plastic, Protective profiles etc
6·Trade Term : FOB Shanghai port or zhangjiagang port ,CIF or CNF to the appointed port
7·Payment : T/T or L/C
8·Delivery : In 20 days after the order confirmed
9·Sample delivery :Two weeks after received your moud fee
10·OEM/ODM orders are welcome
11·If our Aluminum profiles are not suitable for you, you could provide us your samples or technical drawings, we can extruded according to your designs
| Aluminium Alloys | Temper | Rm MPa (min) | Rp0.2 Mpa(min) | A%(min) | A50mm %(min) |
| EN AW-6060 | T4 | 120 | 60 | 16 | 14 |
| T5 | 140-160 | 100-120 | 8 | 6 | |
| T6 | 170-190 | 140-150 | 8 | 6 | |
| EN AW-6061 | T4 | 180 | 110 | 15 | 13 |
| T6 | 260 | 240 | 9-10 | 7-8 | |
| EN AW-6063 | T4 | 130 | 65 | 14 | 12 |
| T5 | 175-160 | 110-130 | 7-8 | 5-6 | |
| T6 | 215-195 | 160-170 | 8 | 6 |
| Aluminium Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti |
| 6063 | 0.20-0.60 | 0.35 | 0.10 | 0.10 | 0.45-0.49 | 0.10 | 0.10 | 0.10 |
| 6061 | 0.40-0.80 | 0.70 | 0.15-0.40 | 0.15 | 0.60-1.20 | 0.04-0.35 | 0.25 | 0.15 |
| 6060 | 0.30-0.60 | 0.10-0.30 | 0.10 | 0.10 | 0.35-0.60 | 0.05 | 0.15 | 0.10 |
| 7075 | 0.40 | 0.50 | 1.2-2.0 | 0.30 | 2.10-2.90 | 0.18-0.28 | 5.10-6.10 | 0.20 |
Our factory Superiority:
Our owns 44 extruion production line introduced from Taiwan, including four 660 tons of aluminum extrusion production lines, five 880 UST,twenty-six 1100 UST, two 1450 UST, one 1800 UST, two 2500 UST, one 3600 UST, one 4000 UST.
We can produce the greatest circumcircle 350 mm and 250mm wall profile and the various industrial profile.
Our biggest width aluminium profile is 420mm.
We have discount for big orders. We can charge free for your molds if your quantity can reach our requirements.
My factory has been established over 15 years. We have over 1300 workers. Quality is promised.
