Help Center308ton Pet Preform Injection Molding Machine
Related Products
We produce PET blowing machine for our customers too.
Here is the Characteristic and technical datas of 308ton PET preform injection moulding machine
1.equiped with servo motor ,
2.closed loop control for pressure and flow .
3.low noise,
4.high precision
5.energy saving .
.
|
INJECTION UNIT |
|
Unit |
LSF-308 |
||
A |
B |
C |
|||
Screw Diameter |
Mm |
60 |
65 |
70 |
|
Screw L/D Ratio |
L/D |
21.6 |
20 |
18.6 |
|
Short Size |
Cm3 |
811 |
952 |
1104 |
|
Injection weight |
G |
738 |
866 |
1004 |
|
Injection Rate |
g/s |
177 |
206 |
239 |
|
Injection Pressure |
Mpa |
193 |
164 |
142 |
|
Screw Speed |
Rpm |
0-185 |
|||
|
CLAMPING UNIT |
Clamp Force |
KN |
3080 |
||
Space Between Tie Bars |
mm |
630X630 |
|||
Toggle Stroke |
mm |
590 |
|||
Max. Mold Height |
mm |
630 |
|||
Min. Mold Height |
mm |
200 |
|||
Ejector Stroke |
mm |
160 |
|||
Ejector Tonnage |
KN |
62 |
|||
Ejector Number |
P |
9 |
|||
|
OTHERS |
Max. pump Pressure |
Mpa |
16 |
||
Pump motor powder |
Kw |
30 |
|||
Heater Power |
Kw |
18 |
|||
Machine Dimension(L*W*H) |
M |
6.15X1.57X2 |
|||
Machine Weight |
T |
10.2 |
|||
Oil Tank Capacity |
L |
640 |
|||
Packaging Detail: |
Plastic film, wood pad, |
Delivery Detail: |
30 days (it is subject to confirmation.) |
Service for installation, training and dispatching the technical
- if user require dispatching our technical for the new machine installation or operation training, the user should afford the fee for our engineer’s round-trip ticket ,board and lodging during installation ,and salary(100USD/day)
Founded in 2001,Changzhou Longsheng Machinery Co.Ltd
Is a professional manufacturer of PP,PE .PPR ,PVC ,PC ABS ,PET …products injection moulding machine ,the clamp force is from 68 ton to 1680ton .injection weight ranges from 60g to 10000g .
With all those advantages and leading technology implementation,LSF series injection molding machines are extremely suitable for the injection molding processing of many different types of plastic productssuch as precision electronics, telecommunication equipment, home appliances, toys, auto parts and so on.
Q: What is the ability of your factory?
A: About injection molding machine, we could produce 40-50 sets machines per month.
Q: Do you have any technical supports about your products?
A: We have many agents in the world , like in Russia , in Egypt, in Iran and in UZ ,etc , which will give you on site technical support, Or we will send you our technical engineer to buyer’s factory for installation ,
Q: Do you have any other service about your products?
A: We have a lot of experience on making complete “Turn-Key” projects and specifications for our clients. Also we have a fixed service system
