Specifications
1) Best value electric vacuum tube furnace2)Single/more/lengthen heating zone tube furnace.
3) KF flange, fast install.
We are a big factory in China, give you factory direct price for electric vacuum tube furnace .
SKGL-1200/1200-Ⅱ open type tube with resistance wire as heating elements, adopted double shell structure and intelligent program temperature control system, phase trigger, SCR control. Furnace chamber adopted imported polycrystalline alumina fiber material, between the double furnace shell with air cooling system, fast heating and cooling, and can open the lid for rapid cooling. Reasonable structure, beautiful appearance.
1. Adopted KF quick flange sealing, only need a clamp flange the connection can be done. It is very convenient to put and take the specimen. Avoiding bolt leakage by artificial operation and reduced the ratio of heating tube damaging which caused by installation flanges;
2. Furnace lid can be opened, real-time observation of the heated material, and can rapidly cool to meet the material suddenly cold and hot experiments;
3. Adopt imported polycrystalline fiber vacuum absorption furnace chamber; the resistance wire is used high quality resistance alloy silk 0Cr27Al7Mo2, servicing time more longer. Max temperature can reach 1200℃;
4. Reserved vacuum, gas road fast interface, could working with our vacuum system or mixed gas system;
5. Reserved 485 convert interface, can be connected with PC through software. It has remote control, real time tracking, history recorder, and output report function. And can be installed the paperless recorder for data storage and output;
6. Built - in thermocouple, real-time monitoring the temperature of the heated material;
7. Cover open automatically power off, over-temperature alarm, leakage protection, safe and reliable operation.
Used for universities, research institutions, industrial and mining enterprises to do high temperature sintering
atmosphere, atmosphere restoring, CVD experimental and vacuum annealing.
Model |
SKGL-1200 |
SKGL-1200-Ⅱ |
Approved by CE certificate, ensure the safety operation of the machine. Certificate No.: GB/1067/4189/12 Issue 1 | ||
Temperature zone settings |
Single heating zone |
Two heating zone |
Heating zone length |
440mm (Customizable) |
220mm/220mm (Customizable) |
Constant temperature zone length |
200mm |
100mm/100mm |
Rated power |
4KW |
4.5KW |
Overall size |
690*410*600mm |
700*480*600mm |
Weight |
80KG |
120KG |
Furnace chamber |
Imported high pure polycrystalline alumina fiber, excellent heat preservation |
|
Furnace tube size |
Φ40/60/80/100*1000mm |
|
Heating elements |
0Cr27Al7Mo2 |
|
Thermometric component |
N-mode thermocouple |
|
Temperature control mode |
The temperature control system uses artificial intelligence technology, with PID control, self - tuning function, 30 the heating and cooling program |
|
Seal mode |
Stainless steel the KF quick flange extrusion seal |
|
Standard vacuum degree |
≤50Pa (If need more high vacuum degree, can purchase different vacuum system) |
|
Working temperature |
≤1150℃ |
|
Max temperature |
1200℃ |
|
Constant temperature accuracy |
±1℃ |
|
Max. Temperature rising rate |
30℃/min |
|
Recommend temperature rising rate |
10℃/min |
|
Working power |
AC220V 50HZ/60HZ |
|
Standard accessories |
Sealed flanges 1 pcs, O-rings 4 pcs, quartz tube 1 pcs, vacuum pump 1 set, pipe plug 4 pcs, oven gloves, crucible tongs each 1 pcs |
|
Optional purchase accessories |
Furnace hobs; Mixed gas system; Low, medium and high vacuum system; All kinds of alumina crucibles; Alumina tube or quartz tube; Computer control software; Paperless recorder, etc. |
|
