AWMD-10 Plastic Injection Water Mold Temperature Control Unit for Industry

Name: AWMD-10 Plastic Injection Water Mold Temperature Control Unit for Industry
Brand: AODE
SKU: 103422933

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Water Temperature Machine

Application:

plastic injection mould,roller,reaction kettle, plate

Shenzhen Aode Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Water Temperature Machine

Application plastic injection mould,roller,reaction kettle, plate

Place of Origin Guangdong, China

Brand Name AODE

Model Number AWMD-10

Temperature Range 25℃~120℃

Temperature Control Accuracy PID±1℃

Dimension(L*W*H) 620*325*645mm

Weight 110kg

Internal Piping Size 3/4*4

Voltage 3N380V50HZ

Power(W) 9+9KW

Certification CE and ISO

After-sales Service Provided Engineers available to service machinery overseas

AWMD-10 plastic injection water mold temperature control unit for industry Quick Detail:

Temp. Control accuracy: PID±1℃
Range of temperature control:+15℃-120℃ for incoming water
Certification:CE & ROHS
Controller:microcomputer
Heating capacity: 9+9KW
Maximum power consumption: 20KW
Alarm function:Excess temperature, open phase, oil starvation, overloading, reverse turn

AWMD-10 plastic injection water mold temperature control unit for industry Description:

Explosion-proof equipment(optional)
Air blowing and return water function(optional)
Thermometer for return water
Automatic air-exhausting function after startup
Switchover of heating power
Instant cooling shut-down function(optional)
RS485 communication function for automated management(optional)
BY-PASS pressure release loop for hot water
Customizable multi-point temperature control unit
Customizable horsepower and heating power of water pump
Brands OMRON, FUJI, TE, LG, MOELLER, ABB, and WEST for electric appliances
Range of temperature control: +15℃-180℃for incoming water
Stainless steel integrated pipelines for less pipe resistance and rust
Control mode: imported microcomputer or PLC(optional)
Perfect safety protection, fault display, easy repair and maintenance even free of professionals

AWMD-10 plastic injection water mold temperature control unit for industry Specifications:

ITEM	UNIT	AWMD-10
Temp control range	℃	Inlet water temperature +15℃-120℃
Temp control accuracy	℃	PID±1℃
Power supply		AC3N380V 50HZ 3P+E(5M)
Heat transfer medium		Water
Cooling method		Indirect Cooling
Heating capacity	KW	9+9
Horsepower of pump	hp	1+1
Working flow of pump	L/min	100+100
Working pressure of pump	Kg/cm2	1.6
Max. power consumption	KW	20
Alarm function		Open phase/water depletion/excess temperature/overloading/reverse turn
Cooling water pipe	inch	1/2
Circulating water pipe	inch	(3/4×4)×2
Size(L×W×H)	mm	620×325×645
Weight	kg	110
