AC-08WD water cooled chiller for Industrial Quick Detail:
High/Low pressure protection for the compressor and overheating protection inside the machine
Low water level alarm and low water temperature alarm
Certification:CE & ROHS
Compressor type: Totally closed vortex type or piston type
Refrigerating capacity: 27370Kcal/h(50HZ)
Warranty:1 year
AC-08WD water cooled chiller for Industrial Description:
High/low pressure protection for the compressor and overheating protection inside the machine
Low water level alarm and low water temperature alarm
Imported compressor from Europe, US and Japan
Refrigerating system welded with oxygen free method, to reduce oxides and ensure the smooth surface
Throttle components from Danfoss (Denmark) and Alco (US)
SUS304 stainless steel water tank, to avoid corrosion or water leak
Stainless plate, coil, shell and tube or fin type efficient heat exchanger
RS485 communication function, to realize automatic management(optional)
Electrical devices supplied from OMRON, FUJI, TE, LG, MOELLER and SCHNEIDER
Control mode: imported micro-computer or PLC(optional)
Perfect safety protection, failure display, and not requiring professional personnel for maintenance
Highly efficient evaporator and condenser, to save over 30% energy
2 compressor heads for over AC-08, for individual or joint operation
AC-08WD water cooled chiller for Industrial Specifications:
ITEM |
UNIT |
AC-08WD |
|
Cooling capacity |
KW50HZ |
24.85 |
|
|
Kcal/h 50HZ |
21375 |
|
Total input |
KW |
6.8 |
|
Maximum Running Current |
A |
16.5 |
|
Power supply |
|
3N-380V 50HZ |
|
Refrigerant |
Name |
R22 |
|
|
Charge |
Kg |
2.2×2 |
|
Control Type |
Capillary Tube |
|
Compressor |
Type |
|
Hermetic scroll or piston |
|
Power |
Kw |
3×2 |
Cooling water |
Flow |
M3/h |
5.34 |
|
In/Out Pipe Size |
G1-1/2” |
|
Chilled water |
Flow |
M3/h |
4.27 |
|
Tank |
M3 |
0.11 |
|
In/Out Pipe Size |
G1-1/2” |
|
water Pump |
Power |
Kw |
0.75 |
|
Pressure |
Kpa |
290 |
Size(L×W×H) |
mm |
1300×610×1445 |
|
Weight |
Kg |
210 |
|
