Description:
This Straw packing machine DNP 38 Series suitable for packing the single pcs straw with bopp film (4 side sealing).It can packing different size straws and no need to change the moulds,just adjusted on the machine. The machine with automatic cutting unit.
Characteristics:
1-Single pcs feeding,packing,cutting finished at once.
2-Packing speed can be adjustment.
3-Automatic counting,and batch alarm.
4-Automatic stop when the package is missing the straw.
5-The packing speed can be adjustment
6-The AC contactor and knob switch brand is SCHNEIDER.
7-The inverter brand is DELTA
Technic data:
Driving motor
0.75kw (control by inverter (DELTA))
Heating power:
2.5kw
Capacity
Straight straw
600-700 pcs/min.
Flexible straw
350-400 pcs/min.
Packing type
Four sides sealing(cooling cutting)
Specification of Bopp film
Max.diameter
340mm
Inner.Dia. of paper core
75mm
width of roll:
280mm
Thickness of film
16-20μm
Specification of straw
Diameter
2.5-7mm
Thickness
0.15-0.35mm
Length
90-250mm (standard)
Dimension of machine
2200mm× 900mm×1600mm
Weight of machine
700kgs
