Bending Beverage straw series flexible straw making machine
flexible drinking straw bending machine Characteristics:
Drink straw makers are composed of frequency extruding system,tooling,cooling sink or vacuum cooling sink,drawing and cutting devices etc.It has such features as reasonable structure and steady operation,each part are all fine finished,There are single-color,double,double-color,tri-color and four-color drink straw makers,which all can produce the various colors straws with the diameter from 1to 14mm.
Application:
This machine is mainly to produce drink straw,sprinkler pipe,cotton stick,candy stick,tooth pick,tooth pick,the refills of ball point pen and water color pen,toy pipe industrial casing pipe,droping tube and other small open pipes etc.It uses the materials such as PE and PP etc.
flexible drinking straw bending machine Main Technical Parameters:
Note:As the products are developing day by day,the technical date are subject change without notice as following:
The colorful plastic drink straw
The cutter of the plastic drink straw making machine
The extruder of the machine
The batch of the machine
The die head of the machine
Inner Diameter of the straw can be customized from 3.5mm to 8.0mm straw length from 245mm to 300mm
2. DNW02 Flexible Straw Bending Machine
Driving motor |
1.5kw control by frequency converter |
||||
Capacity |
200pcs/min |
||||
|
Specifications of the flexible straw |
Inner diameter |
3.8mm |
4.8mm |
5.8mm |
|
Thickness |
0.12~0.20mm |
0.12~0.20mm |
0.12~0.20mm |
||
Length of straight straw |
165~245mm |
200~260mm |
200~260mm |
||
Length of flexible straw |
150~230mm |
185~245mm |
185~245mm |
||
Upper end length |
35~48mm |
||||
Ring amount |
10~12 |
||||
Inner Diameter of the straw can be customized from 3.5mm to 8.0mm,straw length from 245mm to 300mm | |||||
Figure size |
1500*1800*1600MM |
||||
Weight |
900kg |
||||
