Help CenterPCI Express PCie to NGFF M.2 Key-B 2280 SSD With SATA III 6Gbps Expansion Adapter Card
Related Products
-
PCIE Extender Card PCI Express to 2port External USB 3.0 With 19/20pin USB 3.0 Header Expansion Adapter CardUS$ 7.6 - 8.6MOQ: 1 Piece -
4 Ports SuperSpeed 5Gbps USB3.0 PCIe Expansion Card for Desktop PCUS$ 7.6 - 8.6MOQ: 1 Piece
-
PCIE USB 3.0 3 Port Adapter Card With 10/100/1000 Mbps RJ45 Gigabit Ethernet Lan PortUS$ 14.9 - 15.9MOQ: 1 Piece
-
PCI-E Express Adapter to 5 Port USB 3.0 HUB Card With 19/20 Pin USB 3.0 Header Internal Chipset Expansion CardUS$ 9.9 - 10.5MOQ: 1 Piece
-
7 Port 5Gbps USB 3.0 2 Internal PCI-e PCI Express Expansion Card for DesktopUS$ 9.9 - 10.5MOQ: 1 Piece
| Product Model | |
| Model Number | P-LT304-NS |
| Warranty Information | |
| Warranty | 18 months |
| Hardware | |
| Bus Type | PCI Express |
| Card Type | Standard Profile ( Low Profile bracket optional ) |
| Chipset ID | ASMEDIA ASM1061 |
| Industry Standards | Serial ATA Specification 3.0 |
| PCI Express Base Specification Rev. 2.0 | |
| PCI Express M.2 specification 1.0. | |
| Support Native Command Queuing(NCQ) | |
| Interface | SATA III & NGFF M.2 B - Key |
| Port Style | Integrated on Card |
| Ports | 1+1 |
| Supported Drive Height(s) | 2230 ; 2242 ; 2260 ; 2280 M.2 (SATA type) SSD |
| Performance | |
| Maximum Data Transfer Rate | 6 Gbps |
| Type and Rate | SATA III - 6 Gbit/s |
| General Specifications | Not compatible with PCI-Express M.2 SSDs |
| Connector(s) | |
| Connector Type(s) | 1 - PCI Express x1 Male |
| Internal Ports | 1 - NGFF M.2 B - Key Female |
| 1 - SATA (7 pin; 6Gb) Female | |
| Software | |
| OS Compatibility | Windows 10 (32/64), 8 / 8.1 (32/64), 7 (32/64), Vista (32/64), XP (32/64) |
| Special Notes / Requirements | |
| Note |
The maximum throughput of this card is limited by the bus interface. If used with PCI Express Gen 1.0 enabled computers, the max throughput is 2.5Gbps per lane. If used with PCI Express Gen 2.0 enabled computers, the max throughput is 5Gbps per lane. |
| System and Cable Requirements |
PCI Express enabled computer or server with an available PCI Express x1 slot or higher ( x4, x8, x16) |
| Package content | |
| Included in Package | 1 - 2 Port PCI Express NGFF M.2 + SATA Card |
| 2 - NGFF M.2 SSD mounting screws | |
| 1 - Driver CD | |
1. We are the factory manufacturer so we can offer you with quite nice factory price.
2. Our products are all in good quality with nice appearance.
3. All of our products are brand new
4. All our products are packed carefully to ensure it is intact when you receive it.
5. OEM is available and are welcomed. You can request to print your logo or other things on the product by paying us small amount of money.
6. Any questions about us and our products are welcomed. We will answer you with patience.
7. Please kind contact us any time via
Trade Manager: szpanto SKYPE: apscel E-mail: robyhan#
