Specifications
1.good quality with factory pricempt delivery
3.Good construction
4.Good heat resistance
Product Description :
Ultrasonic transducer for all kinds of type we provided.
Piezoelectric transducer uses the piezoelectric effect to realize transduction between electric and sound energy. It comprises a radiation head, electrode, cap, prestressed bolt, piezoelectric chip and an insulating tube.
The piezoelectric transducer is widely used in ultrasonic cleaning machine and high-power industry cleaning devices.
Features :
High efficiency: High mechanical parameter Q, the transduction efficient between electricity and sound above 95%.
High amplitude: The transducer strength is improved by fixing the high speed vibrator directly on the base of washing groove with bolt. Compare with a magnetic expansion vibrator, its amplitude can be improved above 50%.
Good heat resistance: A large range of working temperature, low resonance impedance and heat productivity.
Good construction: Fastened by bolt, easy for assembling, high reliability
1, Pointer ammeter
2, Introduced international leading high-frequency laser line and adopted imported high-frequency power drive, with high pressurization and current, stable output and low breakdown advantages etc. greatly enhance its quality.
3, Soft-start mode, with vibration head short protection, leakage protection and overload protection.
4, Adopt the latest scan mode to avoid the emergence of ultrasonic blind spot, adjusting in the allowed power range 10-100%.
main parameters:
| TIEM | JYD-801A | JYD-802A | JYD-803A | JYD-804A |
| Power range | 600-900W | 900-1500W | 1500-2100W | 2100-2700W |
| Max output current | 3A | 5A | 7A | 9A |
| Work frequency | 20-40KHZ | 20-40KHZ | 20-40KHZ | 20-40KHZ |
| Work voltage | AC220V±10% 50KHZ | AC220V±10% 50KHZ | AC220V±10% 50KHZ | AC220V±10% 50KHZ |
| Dimension size | 370*420*140mm (W*L*H) | 370*420*140mm (W*L*H) | 370*420*140mm (W*L*H) | 370*420*140mm (W*L*H) |
Our service:
1.1and half years free maintenance, all lifetime maintenance service from us;
2. Rechangable within a month, Reply your enquiry in 24 working hours.
3. Experienced staffs answer all your questions in fluent English.
4. OEM is available if the quantity is large.
5. We assure our product of quality, with innovative design, industrial grade quality circuit board, advanced production line and strict quality control procedures, the failure rate is less than 0.01%, which is the lowest in this line.
Shipping information:
1. First step: seal this ultrasonic cleaning machine in PP bags
2. Second step: Use PU foams to fasten and fix the machine
3. The last step: Package it in carton or colour box, seal it, and put up packaging list
