2.4G Wireless Camera With USB DVR Reciever (up to 4 Cameras, Auto-scan)

2.4G Wireless Camera With USB DVR Reciever (up to 4 Cameras, Auto-scan) photo-1
US$ 90 - 100 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SOMAX
Model Number:
SM-WIR0078
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name SOMAX
Model Number SM-WIR0078
Type Digital Camera
Style Mini Camera
Sensor CMOS
Technology Pinhole
Special Features Other, Wireless Mini DVR

Specifications

1.USB 2.0 output to PC
2,Motion detection
3,4 channels available to avoid possible interference
4,High speed real time video

2.4G Wireless Camera with USB DVR Reciever



Features:
Wireless receive and record A/V signal from wireless cameras (up to 4 cameras, auto-scan)
USB 2.0 output to PC, transmission rate up to 480Mpit/s
Motion detection: If any intruder, it alarms with sound, and at same time
capture picture saving in hard disk or send e-mail to long-range PC
High resolution image capture
High speed real time video record
Support MSN Messenger & Skype for long-range live video, like a web camera
Sharp and nature image with true color.
4 channels available to avoid possible interference
Record file format AVI and play with Windows Media Player
Supports Windows 2000/XP/Vista
Small size (100X28X15mm,41g) and beautiful appearance





Camera Specification:
Transmission Frequency ISM 2.4g
Audio subcarrier frequency 6.0Mhz
Antenna Built-in 2.4G antenna
Transmitting Range 300 feet in line of sight
CMOS Total Pixels 510×492(NTSC)
Horizontal resolution 420TV line
Frame rate 30FPS
Built-in mic. 55dB high sensitivity
View Angle 62°
Camera lens focus Beyond3m vicinity:10cm
Minimum Illumination 3.0 Lux / F1.5
Transmission Power  10mW
Battery Performance  Li-ion Battery 160mAH
Working Time  1.5 hours
Charge time 1 hour
Operating voltage DC 5V
Operating current 95MA
Color  Golden/Silver
Dimensions( LX D) 144X12 mm
Weight  30g


Reciever Specification:
Power Supply:  Provided by USB Port
Consumption Current (Max.): 180mA
Receiving Frequency: ISM 2,400MHz~2,483MHz
Input VSWR: 2:1
Demodulation Type: FM
Intermediate Frequency: 480MHz
Frequency Stabilization: +/- 100 ppm
Local Leakage at RF Input Terminal: <=-55 dBm
Receiving Sensitivity: <= -85 dBm
Video Output Signal Impedance: 75 ohm
Video Output Signal Level: 1.0 V +/- 0.15 Vpp
Video Output Signal Polarity: Negative
Video S/N Ratio: 38dB
Audio Output Signal Impedance: 600 ohm
Audio Output Signal Level: 1.25 V +/- 0.25 Vpp / 1 kHz
Audio Output Frequency Range: 250 Hz ~ 10 kHz
Left Subcarrier Frequency: 6.0 MHz
Unobstructed Effective Range: 100 m (Min.)
Dimensions(WxLxH): 10X2.8X1.5cm (Excluding Antenna)
Weight : 41 g



2.4G Wireless Camera with USB DVR Reciever (up to 4 cameras, auto-scan)2.4G Wireless Camera with USB DVR Reciever (up to 4 cameras, auto-scan)2.4G Wireless Camera with USB DVR Reciever (up to 4 cameras, auto-scan)2.4G Wireless Camera with USB DVR Reciever (up to 4 cameras, auto-scan)

2.4G Wireless Camera with USB DVR Reciever (up to 4 cameras, auto-scan)
