Band Shifting Repeater/Frequency Shifting Repeater Series
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
AnyTone
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Fujian, China
Brand Name
AnyTone
Specifications
Shifting repeater using frequency technology is composed of donor and remote units.| Band shifting repeater/Frequency shifting repeater series | |||
| Shifting repeater frequency shifting technology is composed of donor and remote units, while | |||
| one donor repeater+multiple remote repeaters are widely used without optical fiber layout, | |||
| residential network optimization or antenna is not easy installing. | |||
| GSM Band shifting repeater (out-of-band shifting) | |||
| A point | Donor(A point wireless) | B point | |
| Working frequency | GSM:890-915/935-960 | GSM:890-915/935-960 | |
| EGSM:885-915/930-960 | EGSM:885-915/930-960 | ||
| Shifting frequency | 1800MHz band | 1800MHz band | 1800MHz band |
| Clients requirement | Clients requirement | ||
| Bandwidth | Clients requirement | Clients requirement | Clients requirement |
| Gain | 45±3dB | 90±3dB | 90±3dB |
| 30dB adjustable range | 30dB adjustable range | 30dB adjustable range | |
| UL Max power | -10dB | ||
| Shifting Max power | ≥33(2W) | 33(2W) | 33(2W) |
| DL Max power | ≥33(2W) | 33(2W) | 33,37,40,43dBm |
| Monitor | Local and GSM Remote | ||
| GSM Frequency shifting repeater (out-of-band or in band shifting) | |||
| A point | Donor(A point wireless) | B point | |
| Working frequency | GSM:890-915/935-960 | GSM:890-915/935-960 | |
| EGSM:885-915/930-960 | EGSM:885-915/930-960 | ||
| Shifting frequency | 1800MHz band | 1800MHz band | 1800MHz band |
| Clients requirement | Clients requirement | ||
| Bandwidth | 25,30MHz | 25,30MHz | 25,30MHz |
| Channel | 2,3,4 | 2,3,4 | 2,3,4 |
| Gain | 45±3dB | 90±3dB | 90±3dB |
| 30dB adjustable range | 30dB adjustable range | 30dB adjustable range | |
| UL Max power | -10dB | ||
| Shifting Max power | ≥33(2W) | 33(2W) | 33(2W) |
| DL Max power | ≥33(2W) | 33(2W) | 33,37,40,43dBm |
| Monitor | Local and GSM Remote | ||
| CDMA/CELL850/DCS shifting repeaters are available | |||
