PCM300 Silicon Pressure Transmitter
Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
OEM or keram
Model Number:
PCM300
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo or Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Pct Integrative Temperature Sensor TransmitterNegotiableMOQ: 100 Pieces -
PCM600 Air Differential Pressure TransmitterNegotiableMOQ: 100 Pieces
-
PCM600 Air/Gas Differential Pressure TransmitterNegotiableMOQ: 100 Pieces
-
PCM260 Immersion Water/oil Level TransmitterNegotiableMOQ: 100 Pieces
-
Aluminum Alloy Silicon Pressure TransmitterNegotiableMOQ: 100 Pieces
Place of Origin
Jiangsu, China
Brand Name
OEM or keram
Model Number
PCM300
PCM300 silicon Pressure Transmitter
Description
PCM600 differential transmitter is assembled with silicon pressure transmitter.Housing is aluminum
alloy.The two pressure connection have M10 screw thread,so it is easy to connect it with meter machine box or connect through pressure pipe.PCM 600 have mV,standard voltage,current,frequency signal output,etc.for your selection,the installation is very convinient.It is widely used in process control in boiler air supply,under well ventilation of electricity/coal industry.
Specification
| Type | PCM300 |
| Power supply | 12VDC~36VDC(Typical 24VDC) |
| Range | -0.1......0~0.02...100MPa |
| Pressure reference | Gauge Pressure,Absolute Pressure,Seal Pressure |
| Output | 4~200mA.1~5V,0~10mA,0~20mA,0~5V,1~10KHZ |
| Accuracy | 0.1,0.3,0.5for selection |
| Compensated temp. | -10~70°C |
| Permissible medium temperature | -40~125 °C |
| Permissible ambient temperature | -40~85 °C |
| Index protection of outer shell | IP65 |
| Long term stability | ≤0.2%FS/year |
| Zero temp.drift | ±0.03%FS/ °C |
| Span temp.drift | ±0.03%FS/ °C |
| Over pressure | 200%FS |
| Inherent frequency | 5kHz~650kHz |
Typical Dimension
Ordering Example
