General Features:
Coupled with HND diesel engine and Marathon alternator
24V DC start motor
Brushless, Self-excited, IP23, insulation class H alternator
All qualified generator sets are subjected to a comprehensive performance test which includes 50% load, 75% load, 100% load, 110% load and to check, verify that all control systems, alarm and shut-down protection.
Genset Technical Data | |
Prime power |
500 kW |
Standby power |
550 kW |
Rated speed |
1800 RPM |
Output frequency |
60 Hz |
Phase |
3 |
Rated voltage |
440 V |
Engine model |
TBD604BL6 |
Alternator model |
MX-H-550-4 |
Fuel consumption of 100% load |
200g/kw.h |
GB/T13032-2010
ISO9001:2008 Quality Control System
ABS approved
Deutz (HND) Diesel Engine
Technical Data
Engine Model |
TBD604BL6 |
Number of Cylinders |
6 cylinders in V |
Cycle |
4 stroke |
Aspiration |
Turbocharged |
Bore×Stroke |
170 x195 mm |
Compression ratio |
14:1 |
Prime Power/Speed |
600KW/1800rpm |
Speed Governor |
Electrical |
Cooling System |
By radiator |
Fuel Consumption at 100% Load |
200 g/kw.h |
Starter Motor |
DC24V, |
Engine Model |
KTA38-DM |
Number of Cylinders |
12 cylinders in V |
Cycle |
4 stroke |
Aspiration |
Turbocharged and water-air intercooled |
Bore×Stroke |
159 x159 mm |
Displacement |
38 L |
Prime Power/Speed |
880KW/1500rpm |
Speed Governor |
electrical |
Cooling System |
By heat exchanger |
Fuel Consumption at 100% Load |
202g/kw.h |
Starter Motor |
DC24V, |
Marathon Alternator (Standard)
Technical Data
Alternator model |
MX-H-500-4 |
Alternator manufacturer |
Marathon |
Exciter type |
Single bearing, Brushless, Self-excited |
Rated output prime power |
500 Kw |
Rated speed |
1800 RPM |
Rated frequency |
60 Hz |
Phase |
3 |
Rated voltage |
440 V(Available with customer requirements) |
Power factor |
0.8 |
Voltage adjust range |
≥5% |
Voltage regulation NL-FL |
≤±1% |
Insulation grade |
H |
Protection grade |
IP23 |
operation and maintenance manual ABS certificate |
1PC 1PC |
operation and maintenance manual ABS certificate IMO certificate |
1PC 1PC 1PC |
ABS certificate Overall drawings of the set ELECTRINIC SYSTEM DRAWING Bench test Packing list |
1PC 1PC 1PC 1PC 1PC |
operation and maintenance manual |
1PC |
we guarantee that the goods , when correctly mounted and properly operated ,will give satisfactory performance for a period of 12 months starting from the data on which the engines arrive at the port of destination or the genset running 1000 hours ,whichever is first .
During the warrany period , we will remedy any defects by repairing or replacing defective parts of generators free of cost to the buyers
After services and Quality is our company priority
Our company have belows :
1.ISO,CE BV Registration of ISO4001 &ohsas18001 ..certificate
2.reliable performance
3.OEM factory direct sale
If you have any questions , pls don’t hestitated to let us know
skype:janet-ruan
