Specifications
1.silent deutz generator2.global service for 12 month
3.ISO,CE certificate
4.75dB at the distance of 7 meters
1.silent deutz generator general feature:
1) deutz technology
2) soon delivery time
3) best serviec after sales
We are the top VIP supplier on Alibaba ,
authorized by famous certification authority-BV ( Bureau Veritas ).
2. Detuz Diesel Generator Technical Data:
Engine Model |
BF6M1015C-G1A |
Configuration |
4 cycle , 6 cylinders in V |
Aspiration |
Turbocharged and after cooled |
Bore×Stroke |
132x145 |
Rated speed |
1500rpm |
Displacement |
11.906L |
Prime Power |
228KW |
Speed Governor |
electrical |
Cooling System |
Water-cooled , 40°C Radiator As Standard, 50°C Is Optional. |
Speed Stability (%) |
≤5% |
Fuel Consumption at 100% Load |
203 |
Starter Motor |
DC24V, |
Marathon alternator techinical data:
Alternator model |
MP-200-4 |
Alternator manufacturer |
Marathon |
Exciter type |
Single bearing, Brushless, Self-excited |
Rated output prime power |
200 kW |
Rated speed |
1500 RPM |
Rated frequency |
50 Hz |
Phase |
3 |
Rated voltage |
400 V(Available with customer requirements) |
Power factor |
0.8 |
Voltage adjust range |
≥5% |
Voltage regulation NL-FL |
≤±1% |
Insulation grade |
H |
Protection grade |
IP23 |
3.Warranty:
Our warranty will be 1000 accumulative hous or 12 month after shipping, whichever comes first.
4.Certificate & Document:
1) Alternator operation and maintenance manual 1PC
2)Engine operation and maintenance manual 1PC
3)Generator Overall drawings of the set 1PC
4)Electrinic system drawing 1PC
5)Bench test 1PC
6)Packing list 1PC
5.picture of control system and factory:
product for reference
