Specifications
1.generator set price list2.CE,ISO certificate
3.Genuine cummins diesel engine
4.global service for 12 month
1.Generator price list general feature:
1.Coupled with Cummins diesel engine and Stamford Or Marathon alternator
2.24V DC start motor and storage battery
3..Brushless, Self-excited, IP23, insulation class H alternator
4.40°C radiator as standard, 50°C is optional
5.Key start panel control system as standard, digital auto-start panel is optional
6.Optional open type or silent type
7.All generator sets are gone through rigorous testing before being released to the market place, including 50% load, 75% load, 100% load , 110% load and all protection function (overspeed stop, high water temperature, low oil pressure, battery charging fail, emergency stop)
We are the top VIP supplier on Alibaba ,
authorized by famous certification authority-BV ( Bureau Veritas )!!!
2.Diesel generating parameter:
500kw Cummins diesel generator Technical Data Sheet
1.Main technical data of gensets | ||
1.1 |
Model |
JG500GF |
1.2 |
Prime power |
500KW/625KVA |
1.3 |
Prime voltage |
230/400V |
1.4 |
Speed |
1500 rpm |
1.5 |
Weight |
7300kg |
1.6 |
Overall dimension |
4800×1800×2350mm (just for reference) |
2.Main technical data of engine | ||
Cummins engine, 4 stroke. DC start. | ||
2.1 |
Brand |
CUMMINS |
2.2 |
Model |
KTAA19-G6A |
2.3 |
Standby power |
610KW/762.5KVA |
2.4 |
Governor type |
Electronic |
2.5 |
Configuration |
4 cycle , 12 cylinder in V |
2.6 |
Air Intake System |
Tubocharged/ Air and aircooled |
2.7 |
Bore/Stroke |
159×159 mm |
2.8 |
Displacement |
19.0 L |
2.9 |
Starting method |
Electric |
2.10 |
Compression ratio |
14.5:1 |
2.11 |
Fuel consumption |
196g/kw.h |
3. Main technical data of alternator | ||
Alternator is selected the new type brushless alternator designed by US Marathon Electric, which has a unique design, advanced structure, small size, light weight, excellent performance, reliable running and easy-to-use operation. | ||
3.1 |
Brand |
MARATHON |
3.2 |
Model |
MX-500-4 |
3.3 |
Prime power |
500KW/625KVA |
3.4 |
Configuration |
Brushless , self-exciting |
3.5 |
Prime voltage |
230V/400V |
3.6 |
Frequency |
50 HZ |
3.7 |
Power factor |
0.8(lagging) |
3.8 |
Phase/wire |
3 phase 4 wires |
3.9 |
Isolation |
H |
3.Warranty:
Our warranty will be 1000 accumulative hous or 12 month after shipping, whichever comes first.
4.Certificate & Document:
1) Alternator operation and maintenance manual 1PC
2)Engine operation and maintenance manual 1PC
3)Generator Overall drawings of the set 1PC
4)Electrinic system drawing 1PC
5)Bench test 1PC
6)Packing list 1PC
5.picture of control system and factory:
photo for reference
