ABBLEShield BLE 4.0 Module iBeacon/Ar duino/iOS/Android
You can now incorporate Bluetooth 4.0 Low Energy (BLE) technology easily in your project with our ABBLEShield. ABBLEShield requires only a serial port for communication so it supports all major development platforms that have UART interface including Arduino, Raspberry Pi, Netduino, BeagleBone etc.
Features
- Simple interface - with our pre-loaded firmware name ZeroBeacon, you could easily connect to any development board or IC with UART interface.
- Compact form factor - 17mm x 27mm this is a very popular request from makers using smaller Arduino boards like Arduino Mini/Micro/Nano/Pro Mini etc.
- Firmware upgradable - the firmware can upgrade through UART port.
- Support the amazing iBeacon technology and configure the iBeacon with UART port.
Hardware Overview
- On-board chip antenna
- Texas Instruments CC2540 2.4 GHz Bluetooth System-on-Chip (SoC)
- Dimension -17mm x 27mm
- Powering options - 3.3V or 5V
Requirement
Android 4.3
Android devices with BLE hardware: Nexus 4, Nexus 7 and Samsung Note 3
iOS 6 or 7
iPhone 5 (all models), iPhone 4S, iPad Air, iPad (3rd gen or later), iPad mini (all models) and iPod touch (5th gen or later)
Quick Start for iOS
- Connect pins from ABBLEShield to Arduino board
- VIN > 5V or 3.3V. It should connect to 3.3V If it work with 3.3V Arduino. Otherwise it should connect to 5V.
- GND > GND
- TX > RX for Arduino
- RX > TX for Arduino
- Download App LightBlue to test BLE
April Brother Technology Co., Ltd. is the largest iBeacon provider here in China. We have several customers which are the biggest indoor navigation service providers.
50pcs/carton
Package Measurements: 25X20X18 cm Gross Weight: 2.5 kg
you could choose the best shipping way for you , the shipping fee totally depends on the local charges.
Our Service:
1,Customize the case with your logo & customize the firmware of iBeacon
2,Pre-configure the value of parameter before the shipment.
3,Package case can be customized if required.
4,APP & SDK for IOS&Android4.3 provided.
5,We have professional team provide any consultation or advice needed.
6,SDK is available to help customers build their own APP or use our APP.
Waranty:
1. All products and accessories have been tested by 3 times before ship out.
2. All products have 1 year warranty, If there is no man-made problem, we will do our technology service freely.
3. We own the best after-sale service, if any problems happen, Our team will do our best to solve for customer.
Pls be kindly noted that all our products are not send battery due to chinese custom prohibit for shipping.
