Help CenterDC 24V/48V 9000/12000/18000BTU Solar Air-conditioner,DC Compressor Air-condition
Related Products
-
DC 24V/36V/48V Solar Air-condition 9000BTU/12000BTU/15000BTU/18000BTU,DC Compressor Air-conditionUS$ 850 - 1,200MOQ: 1 Set -
DC Solar Split Air-condition 4000BTU/7000BTU/9000BTU/12000BTU/15000BTU/18000BTUNegotiableMOQ: 1 Set
-
Popular Portable Air Conditioner 9000BTU Mobile Remote Air ConditioningUS$ 600 - 750MOQ: 1 Set
-
DC 48V Air Conditioner Standing Type 18000BTU Solar Powered Air Conditioning DC-52GWUS$ 1,000 - 1,200MOQ: 1 Set
-
DC 48V Air Conditioner 18000BTU Solar Powered Air Conditioning DC-52GWUS$ 900 - 1,100MOQ: 1 Set
Specifications
Main features:1.DC solar power input.
2.Power consumption saving.
3.High cooling efficiency
DC Air-conditioner Parameters
Compressor Type |
BD-90E |
Refrigerant |
R134a/R22/R404a/R410(Optional) |
Working displacement(cm3) |
9.0 |
Motor speed(rpm) |
2500-5000 |
Motor Type |
DC Brushless Motor |
Application |
HBP/MBP/LBP |
Capacity (W) |
800-1200 |
Input Power (W) |
200-300 |
Current (A) |
<15 |
C.O.P |
3.5-4.0 |
Lubricant |
Polyester |
Oil Volume (ml) |
480 |
Power Supply (V) |
DC24/36/48(Optional.Custome making special voltage) |
Voltage Range (V) |
DC 24~120 |
Outside Motor Parameters
Motor Type |
DC Brushless Motor |
Voltage |
DC24/48V |
Inpu Power |
45W |
Moter Speed(rpm) |
2800 |
Inside Motor
Motor Type |
DC Brushless Motor |
Voltage |
DC24/48V |
Motor Speed |
2800 |
Model |
KFR25GW/DC |
KFR35GW/DC |
KFR52GW/DC |
||
Voltage (DC) |
24V/48V |
24V/48V |
48V |
||
Refrigerant |
R134a |
R134a |
R134a |
||
Input power (W) |
700-1000 |
730-1300 |
1000-1500 |
||
Cooling capacity (W) |
2500W |
3500W |
5000W |
||
Operation current (A) |
24V |
30-42 |
31-54.5 |
|
|
48V |
15-21 |
15.5-27 |
21-31.5 |
||
Nominal Horse power. |
1hp |
1.5hp |
2hp |
||
Air circulation(m3/h) |
450 |
550 |
800 |
||
|
Noise Db(A) |
Indoor unit |
≤45 |
≤45 |
≤50 |
|
Outdoor unit |
≤52 |
≤55 |
≤58 |
||
|
Net Weight (KG) |
Indoor unit |
10 |
11.2 |
14.5 |
|
Outdoor unit |
35 |
35 |
51 |
||
|
Net Dimension (mm) |
Indoor unit |
795*282*215 |
795*282*215 |
990*330*230 |
|
Outdoor unit |
760*255*525 |
760*255*525 |
850*290*580 |
||
Suitable area(m2) |
10-14 |
15-25 |
25-35 |
||
Remarks:
1.The air-conditon only has cooling function,and the warranty is 1 year;
2.The price is FOB Ningbo port price.;
3.The quotation valid period is 30 days,from 2012-8-20;
4.Our company can produce the special voltage DC air-conditon as clients’ request(Such as 60V/72V/110V etc.).
5.The parameters and photoes only for your reference,the detail data and appearance depends on goods.
