New Original WS-X45-SUP7L-E

New Original WS-X45-SUP7L-E thumbnail-1
New Original WS-X45-SUP7L-E thumbnail-2
New Original WS-X45-SUP7L-E thumbnail-3
New Original WS-X45-SUP7L-E thumbnail-4
New Original WS-X45-SUP7L-E photo-1
New Original WS-X45-SUP7L-E photo-2
New Original WS-X45-SUP7L-E photo-3
New Original WS-X45-SUP7L-E photo-4
US$ 3,000 - 4,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Products Status:
Stock
Ports:
Other
Transmission Rate:
Other
Contact Supplier Request Quote Chat Now
Beijing Skylink Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Beijing/Hongkong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Ports Other
Transmission Rate Other
Certification Cisco
Brand Name CISCO
Model Number WS-X45-SUP7L-E
Place of Origin China







Product Description



DESCRIPTION



The Cisco Catalyst 4500E Supervisor Engine 7L-E is an enterprise-class borderless campus access and price/performance aggregation supervisor engine designed to provide 520 Gbps per system with E-Series chassis. The Cisco Catalyst 4500E Supervisor Engine 7L-E provides unprecedented performance with borderless services such as Flexible NetFlow (FNF) and hosted third-party applications.

The Cisco Catalyst 4500E Supervisor Engine 7L-E builds on the widely deployed line of Cisco Catalyst 4500 supervisor engines and enhances its predecessors to provide nonblocking 48 Gbps per slot bandwidth with Flexible NetFlow for optimized application visibility.




PRODUCT DETAILS
Device Type Control processor
Form Factor Plug-in module
Processor 1 x 1.5 GHz
RAM 2 GB
Flash Memory 1 GB
Performance Switching capacity : 520 Gbps
Per-slot switching capacity : 48 Gbps
IPv6 routing : 110 Mbps
IPv4 routing : 225 Mbps
Capacity QoS hardware entries : 64000
Security services entries : 64000
Virtual interfaces (VLANs) : 4094
IPv4 routes : 64000
IPv6 routes : 32000
MAC addresses : 55000
Spanning Tree Protocol instances : 12000
Switched virtual interfaces (SVIs) : 4094
NetFlow entries : 128000
ARP entries : 47000
Manufacturer Warranty Limited lifetime warranty
Show Detailed Specification

GENERAL
Device Type Control processor
NETWORKING
Form Factor Plug-in module
Connectivity Technology Wired
Routing Protocol PIM-SSM
Remote Management Protocol RMON 1, RMON 2
Performance Switching capacity : 520 Gbps
Per-slot switching capacity : 48 Gbps
IPv6 routing : 110 Mbps
IPv4 routing : 225 Mbps
Capacity QoS hardware entries : 64000
Security services entries : 64000
Virtual interfaces (VLANs) : 4094
IPv4 routes : 64000
IPv6 routes : 32000
MAC addresses : 55000
Spanning Tree Protocol instances : 12000
Switched virtual interfaces (SVIs) : 4094
NetFlow entries : 128000
ARP entries : 47000
Features IPv6 support, Spanning Tree Protocol (STP) support, Quality of Service (QoS), IPv4 support, Link Aggregation Control Protocol (LACP), NetFlow, universal power over Ethernet (UPOE)
Compliant Standards IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.3az
MISCELLANEOUS
MTBF 183,341 hours
Compliant Standards NEBS level 3, CISPR 22 Class A, CISPR 24, EN 61000-3-2, VCCI Class A ITE, EN 61000-3-3, EN55024, EN55022 Class A, EN 61000-6-1, AS/NZS 60950-1, ICES-003 Class A, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, CAN/CSA C22.2 No. 60950-1
PROCESSOR / MEMORY / STORAGE
Processors Installed 1 x 1.5 GHz
RAM 2 GB SDRAM
Flash Memory 1 GB
ENVIRONMENTAL PARAMETERS
Min Operating Temperature 0 °C
Max Operating Temperature 40 °C
Humidity Range Operating 10 - 90% (non-condensing)
EXPANSION / CONNECTIVITY
Expansion Slots 2 (total) / 2 (free) x SFP+
2 (total) / 2 (free) x SFP (mini-GBIC)
Interfaces 1 x management - RJ-45
1 x 1000Base-T (management) - RJ-45
1 x USB - Type A
Compatible Slots 1 x Expansion Slot
MANUFACTURER WARRANTY
Service & Support Limited lifetime warranty
Service & Support Details Limited warranty - advance parts replacement - lifetime - response time: 10 days
COMMUNICATIONS
Supported Flash Memory Cards SD Memory Card
