360 degree pir sensor lamp holder
Model: GD-360
The lamp will switch on automatically when somebody move in the sensor scope;
The lamp will switch off in setting time .
It is widely used in the corridor, basement, bathroom, parking, storage, fire exits, and something else in the building.
Installation
1.Fix the holder in the place where you will want to install accoring to right figure.
2.After installation of the sensor, connect with lamp, then you could test it.
Test
1.After installation, Turned LUX knob clockwise to the maximum (SUN). Turned time knob anti-clockwise to the minimum(-).
2.Turn on the power, the sensor will be electrify and warm-up, 30 sec later, the item will be entered into working estate. 5-10 seconds after the light goes out for the first time and then sesing, the load shoud be worked.
3.Turns LUX knob anti-clockwise to the minimum. If it is tested under the circumstance below 3LUX, load should not work after induction load stop working; but if you cover the detection window with opaque object (towel etc. ) the load works, Under the condition of no induction signals, the load should stop workig within 5-15sec.
Note: when testing in daylight, please turn LUX knobto (SUN) position, otherwise the sensor lamp could not work!
Description:
Working Voltage: 190V-240V 50-60Hz
Max load power:
Incandescent lamp: 75W
Energy saving lamp: 15W
LED lamp:15W
