Amaxtek Best Sale IC Smart Chip Card Reader
Mode NO.:C291
Standard Compliance:
1. Support EMV Level 1 specification
2. Support USB 2.0 full speed
3. Based on ISO7816 implementation
4. Support PC Smart Card industry standard-PC/SC 2.0
5. Support Microsoft Smart Card for Windows
6. Meet Microsoft WHQL USB Smart Card Reader requirements
7. Meet US Federal Information Processing Standards (FIPS) Publication 201
Features:
1. Support single slot
2. Support ISO7816 T=0, T=1 protocol
3. Support I2C memory card, SLE4418, SLE4428, SLE4432, SLE4442, SLE4436, SLE5536, SLE6636, AT88SC1608, AT45D041 card and AT45dB041 card via
4. Support ISO7816 Class A, B and C (5V/3V/1.8V) card
5. Built-in PLL for USB and Smart Card clocks requirement
6. Support software update for memory card module
7. Support Direct Web Page Link via configuration in external EEPROM
8. Support remote wake up through inserting card/removing card
9. Support USB selective suspend
10. Support Power Saving Mode
11.Provide to online bank transaction, online shopping w/credit card.
12.Requirements on smart card reader interoperability
System Requirements
Smart Card: Windows 2003/ XP/ Vista
Attention:
* For Smart Card driver, please install the CD software.
Hardware Installation
Installation the smart card editor software
Open the smart card reader cover and plug in the card
Move USB cover and plug-in the reader to PC
Specifications:
| IC Controller | AU9520 |
| Host Interface | |
| Host Interface | USB 2.0 CCID 1 (also compliant with USB 1.1) |
| Transmission Speed | 12 Mbps (USB 2.0 full speed) |
| Power Supply | Bus powered |
| Smart Card Interface | USB2.0 |
| Standards | ISO 7816 & EMV 2 2000 Level 1 |
| Protocols | T=0, T=1, |
| 2-wire: SLE 4432/42 (S=10), | |
| 3-wire: SLE 4418/28 (S=9), | |
| I 2 C (S=8) | |
| Card Size | ID-1 (full-size) |
| Smart Card Interface Speed | 420 Kbps (when supported by card) |
| Smart Card clock frequency | Up to 5 MHZ |
| Supported card types | 5V, 3V and 1.8V Smart Cards |
| ISO 7816 Class A, AB and C | |
| Power to Smart Card | 60 mA |
| Other Features | |
| Status Indicator | Dual color LED |
| Options | |
| Customer specific logo or label | On request |
| Customer specific colors | On request |
| PC/SC Driver Support | |
| Windows ® 98 / ME, 200 / XP (32bit), 2003 Server | |
| Windows ® CE 5.0 (depending on hardware) | |
| Windows ® Vista (32bit / 64bit) | |
| Linux ® | |
| Hardware Specifications | |
| Demensions (L x W x H) | 83.6 x 65.1 x 9.5 mm |
| Weight | 70g |
| Operating temperature | 0 º -55 º C / 32-131 º F |
| Operating humidity | 10-90% rH |
| Composition | ABS |
| Connector cable | 100 cm / 70.9" |
| Durability | 100.000 insertions |
| Meantime between failure (MTBF) | 500.000 hours |
C291
C290
C292
C293
C294
* We accept T/T, Western Union, Escrow and cash as payment method.
* Cash payment is only available for the customers those can come to our office or store.
* We request 100% prepayment for the sample order. For bulk order, we request 30% deposit; the other 70% should be paid before shipment.
2)Quality Check and Warranty
* One by one chcek to ensure the good quality;
* 12 months warranty, free exchange or repairing service within this period since you paid.
3)Packaging
* Product Package can OEM;
* A carton with 4 inner box; Packing List can do as your requirment.
4)Shipping
* For sample order, we quote you the freight charge;
Use your valid shipping account.
* For Bulk order, use your specific forwarder;
Or we quote you the freight charge.
Amaxtek Electronics Limited, located in Shenzhen, covers an area of 500 square meters. We have walked in this field more than 8 years, and with 5 production lines 80,000 pieces monthly capacity to guarantee the fast leadtime.
