high speed automatic non woven fabric box bag making machine
This machine is suit for non woven fabric material, can fully automatic make non woven bag products with different bag size, as flat bag, shopping bag, gift bag, clothes bag, handle loop bag, vest bag, shoe bag and so on.
Features:
1. This machine adopt Taiwan touch screen computer display, PLC computer program which can be edited.
2. Auto meter counting &stopping, could freely setting number.
3. Computer Fixed-length, printing color mark track orientation, Auto-stop when complete.
4. High voltage static processor, Auto constant temperature heating controller.
5. It could control auto pneumatic handle punching on machine.
6. Unwinding magnetic powder tension control with manual, Auto side-correction control.
7. This machine adopt ultrasonic welding of all aspects, bag mouth folding welding, side sealing, once full completed, fast speed, east to operate, firm sealing, beautiful and decent.
Model |
XKLT-600 |
XKLT-700 |
XKLT-800 |
Max.Bag Length |
580mm |
680mm |
780mm |
Max.Bag Width |
1000mm |
1000mm |
1000mm |
Machine Speed |
30-100bags/min |
30-100 bags/min |
30-100 bags/min |
Max. Fabric Width |
1250mm |
1450mm |
1650mm |
Total Power |
17kw |
19kw |
20kw |
Machine Weight |
2500kg |
2600kg |
2700kg |
Air Pressure |
2Mpa |
2Mpa |
2Mpa |
Material Thickness |
20-110gram |
20-110 gram |
20-110 gram |
Max.Fabric Diameter |
800mm |
800mm |
800mm |
Voltage |
220V |
220V |
220V |
Machine Dimension |
8500*1800*2300mm |
8500*1900*2300mm |
8500*2000*2300mm |
We are manufactory of non wven fabric bag making machine production line, Zipper bg making machine production line, non woven fabric printing machine production line, PVC bag making machine production line and so on.
Any question, please contact us, Thanks!
