Help CenterTAIYITO Android Phone Control Wireless Bidirectional Stable Zigbee Smart Home Automation System
Related Products
-
TAIYITO Android Phone Control Wireless Smart Home Automation Manufacturer High Voltage Zigbee Inteligente KitUS$ 9 - 999MOQ: 1 Unit -
Smart Home Gateway Android Home Automation IEEE802.15.4 ZigBee Standard R&D Manufacturer/ Smart Home SystemNegotiableMOQ: 1 Piece
-
ZigBee Home Automation Manufacturer TAIYITO Home Automation Android Control Domotique HomeNegotiableMOQ: 1 Piece
-
TAIYITO IEEE802.15.4 ZigBee Standard R&D Manufacturer/ Home Automation Wireless SwitchNegotiableMOQ: 1 Piece
-
Building Automation System TAIYITO IEEE802.15.4 Zigbee HA Standard Smart Home Automation KitNegotiableMOQ: 1 Piece
Specifications
1.brushed metal texturelorful,stable,fashionable
3.Zigbee protocol,bidirectional
lorful LED backlight
5.CE
TAIYITO iPhone, iPad or Android Phone Control Wireless Bidirectional Stable Zigbee Smart Home Automation System
Be sure to do networking before installation
What isTYT zigbee smart home automation?
TYT zigbee home automation is new wireless home automation system lanuched by TAIYITO. You can realized residentail housing, office building and hotel intelligent control with this system.
What function TYT zigbee smart home can realize?
- turn off ceilling light and close the curtain when you are on bed in one touch.
- turn all lights and appliances off by your smartphone when you are out
- Kick-start your home thermostat before you leave the office
-and more
-The follow picture show our "TYTsmart" apps on tablet, which can realize home automation controlling remotely( no matter where you are in the world via interent) !!!
What are the advantages of TYT zigbee smart home automation?
-Easy to install and program
-2.4GHz super high wireless frequency communication, so cool and high speed
-The most stable wireless system even in large house
-All products with elegant appearance, optional color of metal drawing frame
What devicesTYT zigbee home automation can control?
-All lights
-TV/Music/DVD/AC
-Heating
-Water heating
-Door lock
-Curtain/roller
-Window
-Fan/vantilator
the specification of the remote control smart home automation
| Name | Zigbee smart home automation |
Zigbee Protocol |
IEEE 802.15.4 |
Function control |
IOS/ Android smart phone long distance control
Scene control;
wall-type centralize control;
remote control;
Timing control
|
Material |
Mental frame |
Installation |
the standard 86 type junction box |
Wireless Transmission Frequency |
2.4GHz |
Appliances |
1 lighting/lamp system, 2 household electric apparatus, 3 window, electric curtain, 4 door lock, 5 AV, background music, 6 home alarm |
| Voltage | AC 95-240V;50-60Hz |
| Dimension |
Front Panel:86x86x13mm; Back Panel: 52x49x26mm |
| Output Power | 300W per gang |
| Data interface | RS485,dry contact,ZigBEE |
| Certification | CE |
How to apply the electric curtain switch of the smart automation product?
— belongs to the controlled products, used in bidirectional ZigBEE system
— receive the wireless 2.4G control signal and transmit related signals, send local control signals of ON and OFF.
— connect with electrical Motor together, control the motor's positive rotation ang reverse to turn on or off surtains and other intelligent functions
— use the remote controller to turn on/off the lamp/electric appliance, check the working status.
— adjust the brightness according to your personal habits
— when in front of the switch, you also can locally control it just like a normal wall switch to turn on/off it
— can be controlled by Scene controller
— the timing control function.
How can it be used when combined with relative matching products?
| with: | Function: |
| the color Programmable Touch Screen Multi-Function Remote Controller(4.3 inches) | control the electric airer motor( it connect with the electric airer touching switch) through the remote controller. |
| TDW6406 color screen programmable wall mount centralized controller | control the electric airer motor( it connect with the electric airer touching switch) through centralized & scene controller. |
| the TDWZ6628 identify encrypted voice long-distance telephone remote controller | control the electric airer motor( it connect with the electric airer touching switch) through the long-distance telephone controller. |
| the TDWZ6617 long-distance network controller | control the the electric airer motor( it connect with the electric airer touching switch) through bring long-distance network controller. |
CE:
