Help Center3m d Type V1.3/1.4 Micro Hdmi Cable
Related Products
Specifications
1.4 micro HDMI Cable1.1.8m,3m,5m,etc,up to 20m
2.Gold plated
3.Suitable for your mobile to HDTV
1.4 micro HDMI Cable
hdmi d type cable
Description:
HDMI D type Micro HDMI Cable
1.High purity oxygen-free copper conductor ensures maximum signal transfer from conductor to connector
2.Gas injected dielectric for greater impedance control
3.High-density triple shield cable isolates signal from EMI and RFI interference
4the best quality of sound and image,100% digital,no compression,no conversion.For all HDMI connectors
5.goods will be tested before shipment.
Micro HDMI specifications: |
|||
| Connector type | HDMI | ||
| Type A | Type C/mini HDMI | Type D/Micro HDMI | |
| Height(receptacle) | About 5.55mm2 | 3.2mm | 2.8mm |
| Width(receptacle) | About 15mm2 | 11.2mm | 6.4mm |
| Pin count | 19 | 19 | 19 |
| Pin pitch(Hortizonetal) | 0.5mm | 0.4mm | 0.4mm |
| Pin rows | 2 | 1 | 2 |
| Insertion cycles | 10000min | 5000min | 5000min |
| applytion | HDTV,PC,etc | DV,camera,etc | mobile,MP4etc |
Molex HDMI Type-D Micro Connectors
The Molex HDMI Type-D Micro Connectors are the world's smallest standard I/O interconnect for hand-held consumer electronics. The HDMI Type-D Micro Connectors are half the size of the current Type-C (Mini) connectors, but deliver equivalent mechanical strength and electrical characteristics, as well as meet HDMI 1.4 specifications. With a 0.40mm (.016") pitch dual-row receptacle, the Molex HDMI Type-D Micro Conectors offer 5,000 mating cycles for durability in mobile applications, friction lock on receptacle shell for excellent retention force and tactile feel when mating, rear receptacle-shell-over-housing design to prevent damage to PCB receptacle, and a receptable terminal hold-down feature to prevent terminal stubbing. The Molex HDMI Cable Assembly is Type-D to Type-A. The Molex HDMI Type-D Micro Connectors deliver high-definition video and images from digital cameras and mobile devices to flat-panel screens.
*High Definition Multimedia Interface Cable
*Micro HDMI Type D Male to HDMI 19Pin Male
*Perfect for connecting your HDMI Monitors, HDTV to your Video / Digital Camera
*Supports all HDMI Devices, including v1.4
*Supports Resolutions up to 1080p
*All conductors and the shields (braid and drain) are copper.
*Gold or nickel Plated Connectors
*Triple shielded.
*Material:RoHS compliance avilable
Applications
| Mobile phones |
| Smart phones |
| Compact handheld devices that can record, store, and play digital video |
| Car Navigation |
| Adapters and Peripherals |
| Ethernet Chann |
| HDMI to Micro HDMI cable 1.8m Package: | ||
| Mease | : | 54*39.5*24.5cm |
| QTY | : | 50PCS |
| N.W. | : | 17.1kg |
| G.W. | : | 19.4kg |
| HDMI-HDMI/dvi cable 5m Package: | ||
| Mease | : | 54*39.5*24.5cm |
| QTY | : | 50PCS |
| N.W. | : | 20.3kg |
| G.W. | : | 21.8kg |
Our Service:
1.OEM d type Micro hdmi cable pack,we could do free design as customer requirement.
2.Qty above 2k,We could use the carton as customer requirement.
3.Protection of your sales area,ideas of design and all your private information.
Payment term:
1.Payment :T/T only,30% deposit,the balance before delivery.
2.Production leading time:5-10day,see qty to confirm.
3.Shipping out:Guangzhou or Shenzhen.
