PQ1000 common rail injector tester Can test SIEMENS. BOSCH, DENSO, DELPHI SIEMENS injectors.
PQ1000 common Rail injector tester with Ultrasonic Cleaning Instrument, add the piezo function .
1. To test if the CR injector is still function, to connect a CR injector to a high pressure fuel source by a high pressure fuel line and to the CR tester by harness. The tester is set to continuous in injection mode. The CR injector
in normal condition, if it is capable to inject fuel under the driving signals by the tester.
2. To test injector spray atomization, to connect a CR injector to a high pressure fuel line and to the CR tester by harness. The tester is set to single injection mode to allow observing the nozzle spray pattern to judge if the nozzle is normal or orifice plugged.
3. Checking the injection return oil and injection oil.
4. With ultrasonic cleaning tester to clean the nozzle.
>>>TECHNICAL DATA
1.High pressure 0-1800bar
2. Check the injector starting pressure
3.Assessment of the injector spray fog quality
4. Inspeciton of the injector spray oil range
5.Check of the injector seal and angel
6.Check of the injector oil flow
7.The machine has fog dissipation convulsion device to improve the work condition.
8.It has the two garde filter to ensure the cleanliness of test.
9.The parameter of common rail injector ( fuel spray counts, frquency, pulse width, pressure etc..)
can be set willfully.
10. it also can clean the common rail injector by Ultrasonic Cleaning Instrument.
Main Voltage(Vac) |
220V |
Main Frequency(Hz) |
50/60 |
Max Filling Volume per Tank(lit./gal) |
2 |
Input System pressure(bar/psi) |
0-10/0-145 |
System Build-up Pressure(bar/psi) |
1-1800bar/0-26100 psi |
We are the leading manufacturer in Diesel Injection Pump Test Bench and Turbocharger in China, already sold more than 100 Countries, include EUI/EUP tester with Cam box, EDC VP37 tester, VP44 teser,RED4 EDC, HEUI tester, DENSO ECD-V3,V4,V5 pump tester,PT Cummins Pumps and Injectors tester, Common Rail injectors and Common Rail Pump tester( CRDI) ,Gasoline pumps and injectors tester and cleaner, Turbo Charger, and Spare parts(plunger, nozzle, head rotor, injector...) also different model tools for pumps and injectors repair. Hope to cooperate with you.
Manager: Lilia Wang
(Skype: nantaiwq)
Mobile: +86-15244106332
QQ: 1326323874
(E- Mail/Skype:dieselnantai@ )
WhatsApp: +86-15244106332
WeChat: +86-15244106332
For details about our products, please contact me by email/skype/mobile phone.
