Specifications
cat5e networking cable best price for buyer1.4*2*0.4mm copper coated steel
2.ANSI/TIA/EIA-568B.2, ISO/IEC1180 BV
cat5e networking cable best price for buyer
1.what is cat5e utp lan cable?:This kind of cable increases the winding density, jacket is a kind of high quality insulation material, transfer rate is 100 MHZ, is used for voice transmission and high transfer rate of 100 MBPS data transmission, mainly used for 100 base-t and 10 base-t network. This is the most commonly used cable: ethernet cable.
2.product structure photo
♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦ ♦
3.Product structure discribion
1)conductor:
* material: solid bare copper(it can be copper coated aluminum or steel)
* conductor diameter.:0.35mm(conductor diameter can be 0.45,0.48,0.5,0.55mm)
*AWG:24 or 26
2). Insulation:
*material: high density polyethylene
*insulation diameter: <=1.0mm
*thickness: 0.18 mm
* quantity: 4 twisted pairs
Blue/white-blue Green/white- green
Orange/white-orange Brown/white-brown
3).sheath:
* material: PVC or LSZH(halogen-free, flame-retardant material)
* Nominal diameter:<=5.50mm
* thickness: 0.55mm
* OD(NOM.mm):4.8
product display:
5.mechanical properties:
*Application area: dray as well as humid rooms
*Temperature (moved): 0°C to 50°C
*Operating temperature: -20°C to +60°C
*Min. bending radius for one-time bending: 4×O.D.(not less than 15 times of the outer diameter when the outer diameter is not more than 40mm and not less than 20 times of the outer diameter when the diameter larger than 40mm.)
*Min. bending radius during installation: 8×O.D.
6. Transmission Properties: ( at 20°C)
TRANSMISSION PARAMETERS:
Insertion Loss(1-100MHz) <=1.967f +0.023f +0.050/f db
NEXT(1-100MHz) >=35.3-15log(f/100) db
PSNEXT(1-100MHz) >=32.3-15log(f/100) db
PSELFEXT(1-100MHz) >=20.8-20log(f) db
RL(1<=F<10MHz) >=20+5log(f) db
RL(10<=F<20MHz) >=25 db
RL(20<=F<100MHz) >=25-7log(f/20) db
Delay(1-100MHz) <=534+36/f db
Delay Skew(1-100MHz) <=45 db
testreport display:
7.Applications:
1. Telecommunications
2. Local Area Network
8.export market:
mainland China, africa oceania eastern Europe , southeast Asia,South America
9.packing process:
first put lan cable into a plastic roller
then into a box
↓
finally wrap the box
↓
factory show
Do you know our producing concept?
We promote the concept of green environmental protection, we produced the jumper wire is low smoke zero halogen and environmental .
Meanwhile,we follow the principle of human base, quality first, keep improving, competitive price , satisfactory service ,cost reduction, well effiency, on time delivery.
