Help CenterDN150MM Multi Dry Dial Stainless Steel Water Meter
Related Products
-
DN100mm Multi Wet Stainless Steel Water MeterUS$ 285 - 300MOQ: 100 Pieces -
Flange Stainless Steel Water MeterUS$ 180 - 510MOQ: 100 Pieces
-
Flanges Connection Large Woltman Irrigation Water Flow Meter DN50-DN300US$ 40.5 - 1,030MOQ: 1 Piece
-
Detachable Dry Dial Woltman Industry Water Meter DN50-DN300US$ 40.5 - 1,030MOQ: 1 Piece
-
Cast Iron Large Caliber Woltman Water Meters DN50--DN600US$ 40.5 - 1,030MOQ: 1 Piece
Specifications
Multi-jet, dry-dial, easy for maintenance;
--Magnetic drive reliable characteristic, long working life;
--ISO4064 Class B
Application:
--Measuring the total volume of cold portable water passing through the pipeline.
Feature:
--Multi-jet, dry-dial, easy for maintenance;
--Magnetic drive reliable characteristic, long working life;
--Vacuum sealed register ensures the dial keep free from fog and frost, Keep the reading clear in a long term service;
--Technical data conform to international standard ISO4064 Class B
Working condition:
Water temperature: 0.1°C~40°C for cold water meter .
0.1°C~90°C for hot water meter.
Water pressure : ≤1.0Mpa or 1.6Mpa
Maximum permissible error:
(1) in the lower zone from qmin inclusive up to but excluding qt is ±5%.
(2) in the upper zone from qt inclusive up to and including qs is ±2%;
Hot water meter ±3%
MAIN TECHNICAL DATA
Type |
Size (mm) |
Class |
Qn Max. Flow |
Qp Nominal Flow |
Qn Transitional Flow |
Qmin Min. Flow |
Min. Reading |
Max. Reading |
M3/h |
L/h |
M3 |
||||||
LXSG-15 |
15 |
A |
3 |
1.5 |
150 |
60 |
0.0001 |
99999 |
B |
120 |
30 |
||||||
C |
22.5 |
15 |
||||||
LXSG-20 |
20 |
A |
5 |
2.5 |
250 |
100 |
0.0001 |
99999 |
B |
200 |
50 |
||||||
C |
37.5 |
25 |
||||||
LXSG-25 |
25 |
A |
7 |
3.5 |
350 |
140 |
0.0001 |
99999 |
B |
280 |
70 |
||||||
C |
52.5 |
35 |
||||||
LXSG-32 |
32 |
A |
12 |
6.0 |
600 |
240 |
0.0001 |
99999 |
B |
480 |
120 |
||||||
LXSG-40 |
40 |
A |
20 |
10 |
1000 |
400 |
0.001 |
99999 |
B |
800 |
200 |
||||||
LXSG-50 |
50 |
A |
30 |
15 |
1500 |
600 |
0.001 |
99999 |
B |
1200 |
300 |
||||||
