Red Color Water Flow Meter In Single Jet Dry Dial For Hot Drinking Water
US$ 6.45 - 6.99
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Gaoxiang Meter
Model Number:
GX/KDS 15-25E-D
Payment & Shipping
Payment Methods:
Port of Shipment:
Qinigdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Volumetric Displacement Type 15mm (1/2") Water Meters and Spare Parts In Brass MaterialUS$ 11.7 - 15.88MOQ: 100 Pieces -
Dry Dial Mechanism for Multi Jet Water Flow Meter Gaoxiang BrandUS$ 1.39 - 1.59MOQ: 100 Pieces
-
Plastic Back Flow Preventer Non-return ValveUS$ 0.12 - 0.19MOQ: 1000 Pieces
-
Black Nylon Material Volumetric Water Flow Meter With Pulse OutputUS$ 10.99 - 15.88MOQ: 100 Pieces
-
DN100 Flanged Connection Woltmann Water Meter in 304 Stainless Steel Water Flow MeterUS$ 161.3 - 483.9MOQ: 100 Pieces
Place of Origin
Shandong, China
Brand Name
Gaoxiang Meter
Model Number
GX/KDS 15-25E-D
Red Color Water Flow Meter In Single Jet Dry Dial For Hot Drinking Water
Metal body water meter One Jet Dry Cold Potable Water Meter
SPECIFICATION
Single- jet Dry Cold Water Meters Brass Material 1/2''-3/4''Inch -- Single Jet Water Meters
| Features |
| 1.Magnetic drive, lower transmission resistance |
| 2.Magnetic shield , for external magnetic field protection |
| 3.Sealed dry dial register ensures clear reading |
| 4.Register can rotate more than 360 for easily reading in any position |
| Installation Requirements |
| 1.The meter should be installed in horizontal position with the register face upwards. |
| 2.The meter must be installed with the direction of the flow as in dicated by the arrow cast in the meter body. |
| 3.Pipel ine must be f lushed before instal lat ion. |
| 4.The meter should be constant ly ful l of water dur ing operat ion. |
| Dimensions and Weigts | |||||||
| Nominal diameter | DN | 13 | 20 | 25 | 32 | 40 | |
| Body thread | D | G3/4B | G1B | G1¼B | G1½B | G2B | |
| Connector thread | d | R1/2 | R3/4 | R1 | R1½ | R1½ | |
| Body length mm | L | 80/110 | 130 | 160 | 160 | 200 | |
| Overall length mm | L1 | 174/204 | 234 | 280 | 284 | 331 | |
| Width mm | W | 80 | 80 | 80 | 110 | 110 | |
| Meter height mm | H | 88 | 88 | 96 | 123 | 123 | |
| Working height mm | H1 | 143 | 143 | 151 | 178 | 178 | |
| Weight without connectors | kg | 0.5/0.6 | 0.7 | 1.05 | 2.1 | 2.43 | |
| Weght without connectors | kg | 0.68/0.78 | 0.98 | 1.57 | 2.89 | 3.47 | |
| 1."L1" is the total length when coupling gaskets without compression. |
| 2.The weight for reference. |
| Main Technical Data | |||||||
| Nominal diameter | DN | 13 | 20 | 25 | 32 | 40.0 | |
| Maximum flow rate m3 /h | Qmax | 3.0 | 5.0 | 7.0 | 12.0 | 20.0 | |
| Nominal flow rate m3 /h | Qn | 1.5 | 2.5 | 3.5 | 6.0 | 10 | |
| Transition flow rate 1 /h | Qt | 120 | 200 | 280 | 480 | 800 | |
| Minimum flow rate 1 /h | Qmin | 30 | 50 | 70 | 120 | 200 | |
| Description of the Register | ||
| Nominal diameter | DN13/20/25/32/40 | |
| Number of black numbered roller | 5 | |
| Number of red numbered roller | 3 | |
| Number of red pointer | 1 | |
| Maximum reading m3 | 99999.9999 | |
| Minimum reading m3 | 0.0001 | |
| Minimum graduation L | 0.05 | |
| Maximum Permissible Error: |
| In the lower zone from Qmin inclusive up to but excluding Qt is ±5% |
| In the upper zone form Qt inclusive up to and including Qmax is ±2% (cold potable water meter) |
