SYD4210 Sun Feeder High Speed Printer Rotary Die-cutter Machine,packing Machine
US$ 10,800 - 15,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, vegetables food fruit etc
Packaging Type:
Cartons
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SS-100 P Thin Blade Slitter Scorer Machine,packing MachineUS$ 4,400 - 8,500MOQ: 1 Set -
SYD4210 Sun Feeder High Speed Printing Rotary Die-cutting,carton MachineUS$ 14,000 - 20,300MOQ: 1 Set
-
YFQ Series of Multi-color Printer Slotter Machine,packing MachineUS$ 6,800 - 22,000MOQ: 1 Set
-
Four-bar Slotting Corner-cutting Machine,packing MachineUS$ 1,500 - 2,400MOQ: 1 Set
-
SYD 4210 Sun Feeder High Speed Rotary Die-cutting Machine,packing MachineUS$ 30,000 - 35,000MOQ: 1 Set
Condition
New
Application
Other, vegetables food fruit etc
Packaging Type
Cartons
Packaging Material
Plastic
Automatic Grade
Automatic
Driven Type
Electric
Power
7KW
Place of Origin
Hebei, China
Brand Name
xinglong
Model Number
SYD4210
Specifications
SYD4210 Sun feeder high speed printer rotary die-cutter machine,packing machine1.adopt lead type
petitive price etc
SYD4210 Sun feeder high speed rotary die-cutter machine,packing machine
Main mechanisms performance
- 1. Adopt lead edge feeding system . Adjust wind volume according bending degree to ensure feeding paper smoothly .
- 2. The rubber roller with air cylinder device ,feeding accurately , stably , not destroy paperboard strength if the feeding space is very small.
- 3. The left and right side baffles adopt electric control with data display(options: pneumatic lifting device ) the back baffle box adopt electric adjustment , the front baffle space by manual adjustment.
- 4. Equipped with colors touch screen take 360 degree set to die roller , display product speed and set production quantity .
- 5. The rubber roller adopt mechanical control the position move left and right .the movement distance is 40mm.
- 6. The space of rubber roller with die roller adopt automatic looking device .and with air cylinder can adjust quickly ,reduce rubber wear ,prolong use lift.
- 7. With speed compensation device make rubber roller rotate with die roller ,make the surface speed of the rubber cushion is completely controlled by dies .The shape of the carton will absolutely equal to the dies.
- 8. With rubber repair device ,the rubber can be used after repaired.
- 9. All of rollers are made of good quality steel .Surface be grinded ,tempering,hard chromed plate.
- 10. Drive roller used good quality alloy steel ,after heat treatment ,be grinded .Gear closed cycle spray lubrication ,automatic balance engine oil device ,keep every unit oil level is equal.
- 11. Main motor use frequency converter adjustment.
Technical parameters:
Model |
Working efficiency(sheets/min) |
Paper-feeding area |
Efficiency die-cutting size |
SYD4210-1800 |
0-120 |
2000×1270 |
1800×1250 |
SYD4210-2000 |
0-60 |
2200×1270 |
2000×1250 |
SYD4210-2200 |
0-60 |
2400×1270 |
2200×1250 |
SYD4210-2400 |
0-60 |
2600×1250 |
2400×1250 |
