Factory Direct Sell Floating Fish Pellet 22kw High Yield Pellet Extruding Machine for Fish Farm Quality Choice

Factory Direct Sell Floating Fish Pellet 22kw High Yield Pellet Extruding Machine for Fish Farm Quality Choice photo-1
Factory Direct Sell Floating Fish Pellet 22kw High Yield Pellet Extruding Machine for Fish Farm Quality Choice photo-2
Factory Direct Sell Floating Fish Pellet 22kw High Yield Pellet Extruding Machine for Fish Farm Quality Choice photo-3
Factory Direct Sell Floating Fish Pellet 22kw High Yield Pellet Extruding Machine for Fish Farm Quality Choice photo-4
Factory Direct Sell Floating Fish Pellet 22kw High Yield Pellet Extruding Machine for Fish Farm Quality Choice photo-5
Factory Direct Sell Floating Fish Pellet 22kw High Yield Pellet Extruding Machine for Fish Farm Quality Choice photo-6
US$ 1,500 - 4,039 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
Mingyang
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Henan, China
Brand Name Mingyang
Model Number PH-95
Type Feed Pellet Machine
Voltage 380V
Power(W) 22+0.75kw
Dimension(L*W*H) 1.9*1.25*0.95m
Weight 860 kg
Certification ISO9001
Warranty 12 Months
After-sales Service Provided Engineers available to service machinery overseas
Product Description

The information of high yield pellet extruding machine

This high yield pellet extruding machine can be used for producing floating fish feed and sinking fish feed. floating pellet machine is suitable for small and middle-sized farm, also can expand corn, rice, broad bean, fish meal, bone meal, blood meal, feather meal. The main folders are Pet feed, fish feed, bullfrogs feed. It is your best help for raising Mink, fox, rat, dog, fish.

The raw material of high yield pellet extruding machine

meat meal, bone meal, fish meal, soybean meal etc. The material for the fish feed machine is easy to get. it could be Flour, corn starch, rice bran,

The requirements for the material

Fineness:Need grind into 60-80mesh

Moisture content : 20-25%

The  application of high yield pellet extruding machine

1.high yield pellet extruding machine is maily proper for frog, aquatic, ornamental fish, pet feed farmers,pet feed, fish farmers, Small and Medium feed factory,institutes of scientific research and so on.

2.The raw materials can be wheat, soybean, cake and other leftovers etc.Its main work principle is changing mechanical energy into heat energy to extrude material.

The technical parameter of high yield pellet extruding machine

we have some type
Type
Screw dia
Power
Capacity
Weight
Machine size(m)
Final size
PH-52
52mm
5.5+0.55kw
50-60kg/h
245kg
1.3*1.0*0.8
1.5-6mm
PH-65
65mm
11+0.75kw
80-120kg/h
420kg
1.2*0.7*0.85
1.5-8mm
PH-75
75mm
15+0.75kw
140-160kg/h
565kg
1.5*1.2*0.9
1.5-8mm
PH-95
95mm
22+0.75kw
250-300kg/h
850kg
1.9*1.25*0.95
1.2-10mm

The working principle of high yield pellet extruding machine

After the material is sent into feeding device, they will be extruded and expanded by the screw shaft with high pressure and temperature which makes the raw material fully cooked and sterilized. Then the expanded material will be formed into pellets by shaping mould. You can change different moulds to make pellets with different diameters. After that a cutting device will cut the formed pellets into different length as required.

Main Features of high yield pellet extruding machine

1 . With different moulds, the machine can produce different diameter food, from 0.9mm to 10 mm. The food can meet different stage fish. The food can be floating 24hours


2 . It can produce different shapes feed for fish, dog, cat etc.


3 .Through the pretreatment of the feed, it can reduce loss of nutrition and advance the protein ratio.So the feed will be digested easily by animals.

The final product of high yield pellet extruding machine

Production of buoyancy puffed feed particles can maintain at least 12 hours don't bubble floating in the water, fish and livestock to eat easy to digest, artificial can easily observe the frog fish to eat, not cause waste of feed,

Packing & Delivery

The packing and shipping of high yield pellet extruding machine

high yield pellet extruding machine packing in the plywood boxes or wooden cases, then put into the 20 feet or 40 feet container in delivery as follows.

Other machine
Our company

for us -------- Gongyi Xiaoyi Mingyang Machinery Plant

Gongyi Xiaoyi Mingyang Machinery Plant is located in Zhengzhou City, which is the biggest manufacturing base of charcoal making machinery.And we are the one of the earliest and largest manufacturers of renewable fuel & energy equipments and related machinery.
our company:

After 15 years development, now our company becomes an independent economic entity with the integration of science, engineering and trading department. our products are widely accepted in both domestic and world market, and also exported to more than 30 countries, such as England, Russia, Sweden, Poland, Iran, Sudan, South Malaysia, Indonesia, Vietnam, etc.

Certifications

We have got many certification such as CE, ISO9001,BV ,etc.
