Stone Crusher Project

Stone Crusher Project photo-1
US$ 1 - 99,999 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Hammer Crusher
Capacity(t/h):
29-42t/h
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai china
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Hammer Crusher
Capacity(t/h) 29-42t/h
Place of Origin Shanghai, China
Brand Name sievo
Model Number all models

stone making machine

stone crusher project



 The  sand   and stone production line plant are crushed preliminarily in the jaw crusher. Secondly, the crushed rough stone materials are transported into the impact crusher for further crush by the belt conveyor. Thirdly, the stone materials are separated into two parts by the vibrating screen, and one part whose size is suitable for the sand making machine will be transported into the sand making machine, and the other part of the stone will transported into the impact crusher. Some of the former part of the stone which are crushed in the sand making machine will turn into required sand, and be washed by the sand washing machine (selectable), and the rest stone materials will be transported into the impact crusher for crush once more.


  This sand production line has features of high automation, low operating costs, high crushing ratio, low energy consumption, large output, convenient maintenance, uniform granularity and good shape of the products, reasonable gradation, and the produced sand conforms to the national standard of construction sand.

      The product of stone production line is widely used in basic construction.
    The whole production process is :
    The raw material are transported to material storage. Then the raw materials fall on to the vibrating feeder. The feeder can extract the soil and other useless stuff from the big stone and feed the big stone to jaw crusher. The out-coming of jaw crusher has a much smaller size. We use a belt conveyer to transfer the smaller stone to impact crusher. We connect the discharge opening of impact crusher with a circular vibrating screen to pick out the stone which has the right size.
    Generally speaking, the stone production line transform big size stone into stone with limited size, which is one very important kind of building material.

stone crusher project

  stone crusher projectstone crusher projectstone crusher project

stone crusher project



No

Max feed opening (mm)

capacity(t/h)

Model

Vibrating Feeder

Jaw Crusher

Impact Crusher

Vibrating Screen

Belt Conveyor(m)

motor power(kw)

1

340

30

GZD2511(3kw)

PE400×600(30kw)

PF1007(45kw)

3YZ1236 (15kw)

60-90(20kw)

120

2

340

50

GZD3117(10kw)

PE400×600(30kw)

PF1007(45kw)

3YZ1545(22kw)

100-130(30kw)

140

3

420

80

GZD3617(10kw)

PE500×750(55kw)

PF1010(75kw)

3YZ1548(22kw)

130-160(30kw)

200

4

480

100

GZD4321(13kw)

PE600×900(75kw)

PF1210(130kw)

3YZ1548(22kw)

140-180(40kw)

280

5

560

150

GZD4321(13kw)

PE750×1060(90kw)

PF1210(130kw)

3YZ1845(22kw)

200-240(50kw)

300

6

630

200

GZD4321(13kw)

PE900×1060(110kw)

PFB1212(140kw)

3YZ2050(30kw)

200(40kw)

350

7

630

250

GZD5027(17kw)

PE900×1060(110kw)

PFB1214(180kw)

3YZ2050(30kw)

200(40kw)

400

8

630

300

GZD5027(17kw)

PE900×1200(110kw)

PFB1214(180kw)

3YZ2160(30kw)

250(50kw)

450

9

700

350

GZD5027(17kw)

PE1000×1200(132kw)

PFB1315(250kw)

3YZ2160(30kw)

250(50kw)

500

10

700

450

GZD6223(28kw)

PE1000×1200(132kw)

PFB1214/2(300kw)

3YZ2145/2 (60kw)

350(60kw)

600
