Vibrating Feeder (Vibratory feeder) is used to transfer the large size materials and granular materials from hopper to receiving device uniformly, periodically and continuously in the production flow and to feed materials into the crusher continuously and uniformly also to screen the materials in the sandstone production line. The vibrating feeder is widely used to match the crushing and sieving equipments in many industries including metallurgy, coal mine, mineral dressing, building material, chemical, grinding, etc.
Feature of Vibrating Feeder:
Smooth vibration, reliable operation, long service life, low noise, low power consumption, easy to adjust, simple structure, easy
Vibrating Feeder is a kind of linear direction feeding equipment. The Vibrating Feeder of Zenith features smooth vibrating, reliable operation, long service life and being suitable for feeding. The feeders are widely used in mining, building-material, silicate and chemical industry in the crushing and screening plants.
In the Sand-Stone production line. The feeder machine can send materials to crusher evenly and continuously and at the same time, it can screen materials roughly. The feeder machine can be used in these areas such as metallurgical industry, coal mining industry, mining-selecting, building, chemical and grinding industry, etc.
Main Technical Parameters of Vibrating Feeder:
Model |
Funnel size (mm) |
Max feed size (mm) |
Capacity (t/h) |
Motor power (kw) |
Weight (t) |
Overall dimension (L×W×H) (mm) |
ZSW-850×3000 |
850×3000 |
400 |
80-120 |
7.5 |
4 |
3110×1800×1600 |
ZSW-960×3800 |
960×3800 |
500 |
120-210 |
11 |
4.4 |
3850×1950×1630 |
ZSW-1100×4900 |
1100×4900 |
580 |
280-450 |
15 |
5.4 |
5200×2050×1700 |
ZSW-1300x4900 |
1300×4900 |
650 |
450-600 |
22 |
6 |
5200×2350×1750 |
ZSW-1500×6000 |
1500×6000 |
800 |
600-1000 |
30 |
8.8 |
6082×2660×2400 |
