Home > Packaging & Printing > Packing Machinery > Laminating Machine > SMMCM-2 Magnetic Stripe Bonding Machine
SMMCM-2 Magnetic Stripe Bonding Machine
US$ 4,333 - 5,833
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
SmartManufacture
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SMMCM-1 Magnetic Stripe Applying MachineUS$ 28,333 - 31,166MOQ: 1 Set -
SMMCM-3 Magnetic Card Making MachineUS$ 21,000 - 31,166MOQ: 1 Set
-
Ink Jet Printing PVCUS$ 0.098 - 0.115MOQ: 1000 Sheets
-
SMCOF-1 Coated Overlay FilmUS$ 0.041 - 0.057MOQ: 4000 Sheets
-
Digital Printing PVC for Making CardUS$ 0.106 - 0.3MOQ: 1000 Sheets
Condition
New
Place of Origin
Zhejiang, China
Brand Name
SmartManufacture
Model Number
SMMCM-2
Voltage
380V or 220V or 110V
Power(W)
3KW
Dimension(L*W*H)
800mm*700mm*1500mm
Weight
200KG/250KG
Certification
CE, ISO9000:9001
Warranty
one year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
SMMCM-2 mgnetic Bonding Machine is used for making magnetic stripe on PVC sheet or PVC roll, make magnetic card, credit card.SMMCM-2 Magnetic Stripe Bonding Machine
Feature Use double cylinders to be motivity,the pressure of the welding spot can be adjusted,the magnetic strip welding spot is level off and firm. Heating temperature control method:use the heater to heat up and the import thermocouple cooperating with temperature controller to control the temperature,it is easy to set and the temperature controller is precision.The spot welding time controlled by time relay and the time can be adjusted as needed,It is simple and convenient for setting.
| Suitable Materails | PVC, ABS, PET, PETG, Teslin or other mixed plastic mateials |
| Material Thickness | 0.06mm-0.8mm sheet |
| Voltage Input | 380V 50/60Hz |
| Power | 3KW |
| Air Supply | 0.6MPa 6KG/cm2 no water |
| Magnetic Tape Size | 12.7mm or other special size in your order |
| Temperature Range | 0-400 centigrade |
| Temperature Precision | 2 centigrade |
| Magnetic Stripe numbers | 2*5, 3*7, 3*8, 3*9, 4*8, 4*9, 5*5 or other format in your order |
| Pressure Method | air and hydraulic pressure |
| Heating Method | heating tube |
| Working Efficiency | 230-400 sheets per hour |
| Packing Size | 800mm*700mm*1500mm |
| Net/Gross Weight | 200KGS/250KGS |
