Three in One Tuner, DVB HD Receiver Sunray4 DM800 se SR4

Three in One Tuner, DVB HD Receiver Sunray4 DM800 se SR4 thumbnail-1
Three in One Tuner, DVB HD Receiver Sunray4 DM800 se SR4 photo-1
US$ 178 - 189 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Sunray
Model Number:
sunray4 HD se
Contact Supplier Request Quote Chat Now
Shenzhen Tenry Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Sunray
Model Number sunray4 HD se
FTA(Free To Air) Yes
Type Digital
High Definition Yes

Specifications

Sunray4 DM800 se SR4
1. 400mhz processor
2. Three-in-One DVB-S/C/T
3. Colored LED display
4. Wifi

Three in One Tuner, DVB HD Receiver Sunray4 DM800 se SR4

Sunray4 HD se



DVB-S C T 3 in 1 Triple tuner with wifi

  • 1. 400 MHz MIPS Processor (800-HD only has 300MHz.)
  • 2. Colored OLED Display (500-HD do not have)
  • 3. HDMI connector. (Not DVI connector)
  • 4. Plug & Play Slot for an internal2,5" SATA hard diskor eSATA.
  • 5. 10/100 MBit compatible Ethernet Interface.
  • 6. Plug & Play Tuner(Can Change the Tuner into DVB-C, DVB-T.)
  • 7. 3 x USB 2.0(500HD only have one)
  • 8. 2 X Smart Card-Reader (800HD only have one.)

show pictrues:

Three in One Tuner, DVB HD Receiver Sunray4 DM800 se SR4Three in One Tuner, DVB HD Receiver Sunray4 DM800 se SR4Three in One Tuner, DVB HD Receiver Sunray4 DM800 se SR4Three in One Tuner, DVB HD Receiver Sunray4 DM800 se SR4Three in One Tuner, DVB HD Receiver Sunray4 DM800 se SR4







Features:

  • 400 MHz MIPS Processor
  • Enigma 2, Linux Operating System
  • colored OLED - Display
  • MPEG-2 / H.264 Hardware decoding
  • Tuner: DVB-S, optional: DVB-C, DVB-T
  • Tuner Module, Plug&Play
  • 2 x Smartcard-Reader (Dreamcrypt CA)
  • Mini USB for Service and software update
  • 10/100Mbit Ethernet Interface
  • 1 x Scart (RGB, FBAS or S-Video)
  • HDMI
  • 2 x USB 2.0 (e.g keyboard)
  • analog modem
  • S/PDIF Interface for digital bit stream out (AC-3)
  • 64 MByte Flash, 256 MByte RAM
  • SATA - for internal HDD 2,5“
  • unlimited channel lists for TV/Radio
  • channel-change time < 1 second
  • automatic service scan
  • directly bouquet-lists
  • EPG (electronic program guide)
  • multiple LNB-Switching control (supports DiSEqC)
  • OSD in many languages and skin-support
  • Videotext Decoder
  • extern 12V power supply
DVB 800 HD se technical data DBS-Tuner mit DVB-S2:
  • Frequency Range 950 .... 2150 MHz
  • Demodulation DVB-S (QPSK); DVB-S2 (8PSK,QPSK)
  • Symbol rate DVB-S: 2 ... 45 Mbaud/s, SCPC/ MCPC
  • DVB-S2: 10 – 31 Mbaud/s (8PSK) , 10 –30 Mbaud/s (QPSK)
Video decoder:
  • Video Compression MPEG-2 and MPEG-1 compatible, H.264
  • Video Formats 4:3 / 16:9
  • Letterbox for 4:3 TV-Device
Audio decoder:
  • Audiokompression MPEG-1 & MPEG-2 Layer I and II, MP3
  • Audio Mode Dual (main/sub), Stereo
  • Frequency: 32 kHz, 44.1 kHz, 48 kHz, 16 kHz, 22.05 kHz, 24 kHz
Output analog:
  • Output Level L/R 0,5 Vss on 600 Ohm
  • THD > 60 dB (1 kHz)
  • Crosstalk < -65 dB
Output digital:
  • Output Level 0,5 Vss on 75 Ohm
  • Sampled Data Filtering 32 kHz, 44.1 kHz, 48 kHz
  • S/PDIF-Output optical, Toslink
Ausgang Video:
  • Ausgangspegel FBAS 1 Vss +/- 0.3 dB an 75 Ohm
TV-Scart:
  • Output: FBAS, RGB, S-Video
Mini USB service connector:
  • Function: Update of Firmware
Ethernet:
  • 10/100 MBit compatible interface
  • Function: Update of Firmware
SATA Interface:
  • for internal 2,5" HDD
USB
  • 3 x USB 2.0
LNB power and polarisation per tuner:
  • LNB Current 500mA max.; short-circuit-protected
  • LNB Voltage vertical < 14V no load, > 11,5V at 400mA
  • LNB Voltage horizontal < 20V no load, > 17,3V at 400mA
Count of active satellite position:
  • DiSEqC 1.0/1.1/1.2 and USALS (Rotor Control)
Power consumption:
  • < 15W at 12V
External PSU
  • Input: 110-240V AC / 50-60Hz / 0,6A
  • Output: 12V = / 3,0A
Physical specification:
  • Ambient Temperature +15°C...+35°C
  • Humidity < 80%
  • Size (W x D x H): 225 mm x 145 mm x 52 mm
  • Weight: 940 g without HDD
Package including :
  • 1*800HD SE Receiver Box
  • 1*1.5M HDMI-HDMI Cable
  • 1*Remote Controller
  • 1*Power Suppply With Cable(EU/US/AU/UK Plug)
  • 1*AV Cable
  • 1*Scart Covert

Three in One Tuner, DVB HD Receiver Sunray4 DM800 se SR4Three in One Tuner, DVB HD Receiver Sunray4 DM800 se SR4
