Industrial Finned Air Heater
Industrial Finned Air Heater are constructed like basic tubular elements with the addition of continuous spiral fins, 4-5 per inch permanently furnace brazed to the sheath. Fins greatly increase surface area and permit faster heat transfer to air, resulting in lower surface element temperatures.
Finned heater tubular feature:
1.We offer standard as well as customized models
2.We offer different tube diameters like 6 mm, 8 mm, 11 mm, 12.5mm, 16mm & 18mm
3.We offer different sheath materials. It can be availed in different materials like Incoloy 800, SS 304, SS 321, SS 316, Copper & Titanium
4.We offer various shapes as customer demand:immersion heater with flange or screw, explosion proof heater.
5.Various terminal options are available
Finned heater tubular applications:
Drying------Heat Treating------Annealing------Load Banks------Curing
Finned heater tubular drawing for reference:
Finned heater tubular structure of tubular heating element:
| finned heater tubular HI-POT TEST | 1500V/S min cold condition |
| finned heater tubular insulation resistance | 20M Ω min |
| finned heater tubular leakage current | 0.75ma max |
| finned heater tubular power tolerance | +5%,-10% |
| finned heater tubular voltage | 12V-440V |
| finned heater tubular diameter range | 1mm to 40mm |
| finned heater tubular heating resistance wire | 0Cr25Al5,Cr20Ni80 or as custom's requirement |
| finned heater tubular air tubular heater wattage | ≥ 2w-10w/cm2 |
| finned heater tubular water tubular heater wattage | ≥ 6w-20w/cm2 |
| finned heater tubular dies and fin tubular heater | ≥ 8W-15w/cm2 |
Quality and service:
