Two Storey Modern Prefabricated Villa

US$ 110 - 150 MOQ: 150 Square Meters

Key Specifications

Place of Origin:

Guangxi, China

Brand Name:

Model Number:

villa

Guangxi Weiguan Modular House Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

fangcheng port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangxi, China

Brand Name WG

Model Number villa

Prefabricated villa

The prefab house: low price, economic , elegant, good apperance, bright color.

Total SMQ: 200,3 bedrooms, 2 dining rooms, 2 washrooms, 2 stories.

Length: 3m	Width :10m	Height:10m	Total square:100
capacity:150kg/	Resist wind: Ten level	Druable time: 10 years 15 years 20 years	Delivery timein 3-10 days
Payment: by T/T OR L/C	FOB price:USD90-150	Total price: USD	Packing information:use the wood to fixed the material
Application: Family suit, prefab villa	Bedrooms: 3	Living rooms: 1	Kitchen:1
Bathrooms: 2	MOQ:150SQM	The main material : 75mm EPS sandwich pannel for wall and roof 8# C type steel for pillar	The trait:low price ,good quality, elegant , good apperance, bright color fireprotet , waterproof, easy transport, fast shipment, assemble and dissamble quikly flat surface and art decoration

two storey modern prefabricated villa main material list as bellow
Post/Column	first floor:140×70mm square steel; second floor:80×80×2.0 square steel,100×50×1.5 flat steel
1 beam	120×50mm mild steel channel
arch bridge	100×50×1.5 flat steel
Ring beam	80×40×1.5 flat steel
Roof purlin	80×40×1.5 flat steel
purlin	120×50×1.9 C# steel
horizontal support	L50×3.0 steel
steel stairway	120*50 standard steel structure stair,3mm steel board
railing	60×40 flat steel, 35 square steel,5.0mm coment borad,3.0mm steel board
floor slab	18mm polywood
Roof tile	75MM corrugated tile
External wall	50mm EPS sandwich panel(the two side are galvanized color steel sheet,thickness is 0.326mm)
Internal wall	50mm EPS sandwich panel(the two side are galvanized color steel sheet,thickness is 0.326mm)
Door	50mm wooden door; 50mm EPS sandwich panel(the two side is galvanized color steel sheet,thickness is 0.326mm)
Window	20002200,11501000 plastic steel sliding window;800*500 steel shutter,4mm thickness glass
galvanizing channel	2720×30×30(galvanizedchannel)
hang ceiling	200*6000 plastic gusset plate
