Help CenterATMEGA164PA-AU(Integrated Circuit)LQFP
Related Products
-
LT3060ITS8-1.8#TRPBF (LT/LinearTechnology) SOT23-8US$ 1 - 40MOQ: 5 Pieces -
LT3050IMSE-3.3#TRPBF (LT/LinearTechnology) MSOPUS$ 1 - 40MOQ: 5 Pieces
-
LT3014HVEDD#TRPBF (LT/LinearTechnology) QFNUS$ 1 - 40MOQ: 5 Pieces
-
LT3014EDD (LT/LinearTechnology) DFN-8PUS$ 1 - 40MOQ: 5 Pieces
-
LT3014BHVES5 (LT/LinearTechnology) SOT23-5US$ 1 - 40MOQ: 5 Pieces
Specifications
1.hot sale ATMEGA164PA-AU(Integrated circuit)2.New Original
3.Best price,Excellent quality
4.In stock,Fast delivery
Features
• High-performance, low-power 8-bit AVR® Microcontroller
• Advanced RISC architecture
– 131 powerful Instructions – most single-clock cycle execution
– 32 × 8 general purpose working registers
– Fully static operation
– Up to 20MIPS throughput at 20MHz
– On-chip 2-cycle multiplier
• High endurance non-volatile memory segments
– 16/32/64/128KBytes of In-System Self-programmable Flash program memory
– 512/1K/2K/4KBytes EEPROM
– 1/2/4/16KBytes Internal SRAM
– Write/Erase Cycles: 10,000 Flash/ 100,000 EEPROM
– Data retention: 20 years at 85°C/ 100 years at 25°C (1)
– Optional Boot Code Section with Independent Lock Bits
In-System Programming by On-chip Boot Program
True Read-While-Write Operation
– Programming Lock for Software Security
• Atmel QTouch® library support
– Capacitive touch buttons, sliders and wheels
– QTouch and QMatrix acquisition
– Up to 64 sense channels
• JTAG (IEEE std. 1149.1 Compliant) Interface
– Boundary-scan Capabilities According to the JTAG Standard
– Extensive On-chip Debug Support
– Programming of Flash, EEPROM, Fuses, and Lock Bits through the JTAG Interface
• Peripheral Features
– Two 8-bit Timer/Counters with Separate Prescalers and Compare Modes
– One/two 16-bit Timer/Counter with Separate Prescaler, Compare Mode, and Capture Mode
– Real Time Counter with Separate Oscillator
– Six PWM Channels
– 8-channel, 10-bit ADC
Differential mode with selectable gain at 1×, 10× or 200×
– Byte-oriented Two-wire Serial Interface
– Two Programmable Serial USART
– Master/Slave SPI Serial Interface
– Programmable Watchdog Timer with Separate On-chip Oscillator
– On-chip Analog Comparator
– Interrupt and Wake-up on Pin Change
• Special Microcontroller Features
– Power-on Reset and Programmable Brown-out Detection
– Internal Calibrated RC Oscillator
– External and Internal Interrupt Sources
– Six Sleep Modes: Idle, ADC Noise Reduction, Power-save, Power-down, Standby and
Extended Standby
• I/O and Packages
– 32 Programmable I/O Lines
– 40-pin PDIP, 44-lead TQFP, 44-pad VQFN/QFN/MLF
– 44-pad DRQFN
– 49-ball VFBGA
• Operating Voltages
– 1.8 - 5.5V
• Speed Grades
– 0 - 4MHz @ 1.8 - 5.5V
– 0 - 10MHz @ 2.7 - 5.5V
– 0 - 20MHz @ 4.5 - 5.5V
• Power Consumption at 1MHz, 1.8V, 25°C
– Active: 0.4mA
– Power-down Mode: 0.1µA
– Power-save Mode: 0.6µA (Including 32kHz RTC)
Please let us know if you would like to know more about ATMEGA164PA-AU(Integrated circuit) LQFP . Please feel free to contact us.
Device |
Flash |
EEPROM |
RAM |
Units |
ATmega164A |
16K |
512 |
1K |
bytes |
ATmega164PA |
16K |
512 |
1K |
|
ATmega324A |
32K |
1K |
2K |
|
ATmega324PA |
32K |
1K |
2K |
|
ATmega644A |
64K |
2K |
4K |
|
ATmega644PA |
64K |
2K |
4K |
|
ATmega1284 |
128K |
4K |
16K |
|
ATmega1284P |
128K |
4K |
16K |
Manufacturer Part Number: |
ATMEGA164PA-AU(Integrated circuit)LQFP |
Manufacturer / Brand: |
Original Brand |
Quantity Available: |
2000(contact us to confirm the available quantity) |
Unit Price: |
Contact us |
D/C (Date Code): |
Generally newest 2014+ |
Lead Time (Delivery Time): |
IN STOCK, Fast delivery |
Condition: |
NEW AND UNUSED, ORIGINAL FACTORY PACKING |
Package / Case: |
PDIP/TQFP/VQFN/QFN/MLF |
Packaging: |
Factory sealed packing |
SPQ (Standard Package Quantity): |
Contact us |
MOQ: |
20Piece |
Datasheet Download: |
Contact: winwin-ke@hotmail TradeManager:winchips /skype:win-chips |
Finding the Right NAND Solution
The manufacturer has been developing leading-edge memory technology for more than 30 years. Their long tradition of innovation and technology leadership has helped shape their broad NAND Flash offering. With high-performance NAND products that cover everything from mobile, to embedded, to enterprise storage applications, they can help you find the best solution for your design.
Overview |
Benefits |
Densities |
Configurations |
Supply Voltages |
|
128Mb–512Gb |
x1, x8, x16 |
1.8V, 3.0V, 3.3V
|
|
|
16Gb–1Tb |
x8 |
3.3V |
|
|
64Gb–128Gb |
x8 |
3.3V |
|
|
1Gb–4Gb |
x1 |
3.3V
|
Factory sealed packing,and sended in the following types: Tube, Tray, Tape and Reel, Bulk packing, Bag, etc. Please kindly confirm with your sales if you need any other assistant or demand.
Delivery time:
The goods will be shipped within 1-2 working days after confirming buyer’s payment. If you are in urgent need, we will arrange the shipment on the very day.
Shipment:
1.If you don’t have a account with any courier, we will arrange shippment and prepay the shipping cost here.
2.The item you order will be sent by DHL, UPS, FedEX, TNT and etc. If you prefer any other shipping ways, please tell us and we will check whether it is available. We will ensure the lowest shipment cost.
- if your address is remote area , you need to pay the extra charge of DHL $USD35,other wise we will send the package by EMS.Hope your kindness understanding .Thanks!
- for the customs value , if you have special requirements ,pls let us know . otherwise we will do it as our regulation (usually $USD10-20)
Tracking:
When our colleague sell your parts out. The tracking number will be e-mail to you immediately. Please confirm the receipt of the products if you receive the parcel.
Quality Control:
Before each shippment, our every product must be examined. If it fail to pass our internal inspection, we will inform you at the right time.
Refund&Replacement:
If some of the items you received aren’t in exact conform with your requirs. We would still responsibly arrange your refund and replacement. The return items must remain their original condition as same as what we sent to you.
-
Pls contact us within warranty period(1 months ). Warranty doesn’t include any man-made damage
Others:
Any other request, please feel free to contact with our salesman.
Company InformationCertificate of Conformity
Quality testing machine
Our company
Warehouse
If you need any other similar product manufacturers.Pls contact us. And if you have orders please do not hesitate to discuss the price with us.
More than 5,000,000 ownstock inventory to meet your needs of different products.(we cannot show them out all)
Competitive price advantage helps to save your purchase cost and your precious time.
About the price please check up with our customer service.
