Product Description

 DIP whole line equipment for pcb assembly

Tech-specifications



the whole line is made /connected one by one section .



Normal Dimensions : 2.5m*0.9m *1.6m (L*W*H) can made by your requirements.



1.  2.4 meters/section, each section can be configured for 3-4 station, motor Imported from Tai Wan 60 w with 1:50 tooth transmission system, electronic stepless speed regulation

2.The skeletons using 40 x 40 mm stainless steel materials, table plate use δ2 iron plate bending forming, beautiful and durable

3.Speed range :0.3 - 3m /min can be regulated ( automatic running)

4.PCB size : 50 -300mm available

5.. The chain rail choose ETA special aluminum 51 * 56

6.Use nylon chain transmission, high precision, smooth transmission

7.Each section Equipped with  3 sets of A4 plastic document fixtures for  process procedure guide

8.One working place one power sockets

9. With W170 parts box connected to the move rail , convenient to insertion and  save Labor

10..Each section has two 30W tube lights ,, independent switch

11.Power supply 1φ 220VAC 50Hz

12.Steel surface :computer white paint .

CFL insertion line,

Automatic PCB & CFL insertion line for dip,

PCB insertion line for dip production line, Dip insertion line,

Insertion line : insertion components on the board ,insert components on pcb,

dip line pcb dip assembly line insertion line with pcb width adjustble

Technical specificatin:



1.  2.4 meters/section, each section can be configured for 3-4 station, motor Imported from Tai Wan 60 w with 1:50 tooth transmission system, electronic stepless speed regulation



2.The skeletons using 40 x 40 mm stainless steel materials, table plate use δ2 iron plate bending forming, beautiful and durable



3.Speed range :0.3 - 3m /min can be regulated ( automatic running)



4.PCB size : 50 -300mm available



5.. The chain rail choose ETA special aluminum 51 * 56



6.Use nylon chain transmission, high precision, smooth transmission



7.Each section Equipped with  3 sets of A4 plastic document fixtures for  process procedure guide



8.One working place one power sockets



9. With W170 parts box connected to the move rail , convenient to insertion and  save Labor



10..Each section has two 30W tube lights ,, independent switch



11.Power supply 1φ 220VAC 50Hz



12.Steel surface :computer white paint .

DIP whole line equipment for pcb assembly

1.Type: single belt ,opposite seats ( side seats ) (PDX)
2.Workers' seat: ( length of line accord to customer requirments )
3.Length for seat: 2000mm, total length 20m. (The length can accord to customer's
requirement. )
4.Total width for production line: belt width 400mm,working table width 400mm
5.Total height for production line: about 2000mm, working surface level, 720-750mm(adjustable).
6.Speed: 0.3-3m/min ( adjustable).
