Application range
Cetane machine in accordance with ASTM D613, GB/T386 or standards fixed ignition lag measured cetane number of diesel and biodiesel, this product is suitable for nature of sample with a known ignition diesel cetane standard fuel (cetane and heptamethy l nonane mixture at a volume ratio) comparing ignition properties determined. specific method is to change compression ratio of engine Graduated flask, in order to obtain determined ignition lag (delay) period, fuel injection start and combustion (combustion) time interval between start. When sample or standard fuel in combustion process, this time interval should be fixed at 20 ° (crank angle of generator meter), but different fuel required for combustion of different compression ratio, which is end of compression stroke, temperature and pressure are different. Compression ratio according to sample gas is not more than five scale readings select two standard fuel cetane units, obtained in same way to determine ignition lag. When sample gas compression ratio scale reading in one of two standard fuel gas between scale readings, sample is calculated is designed and made as per interpolation of cetane number, symbol × ×.× / CN. For example 45.6/CN.
Function Features
1, easy to operate.
2, standard oil with less (measured with ASTM cetane save 50% or more machine than).
3, measurement Precision (compared with ASTM cetane measuring machine).
4, to determine conditions faster (20-30 minutes).
5, measured sample speed.
6, green (with a unique spray wash exhaust).
7, low noise (a muffler tank).
8, variable compression ratio adjusted freely.
packaging details:wooden packing
delivery details:15business days ,by air or by ship
Friend Instrument Company is more than a technical instrument manufacturer. We are committed to providing you with full support for your laboratory testing needs. Our extensive range of support services is brought to you by our staff of technically knowledgeable, trained specialists who are experienced in testing petroleum products and servicing instrumentation. We take care of you through the whole process before and after your purchase from Friend.
LUBRICATING OIL TESTS
Bearing Compatibility, Cloud & Pour Points, Coking Tendency, Copper Strip Corrosion, Corrosion of Lead, Corrosivity / Oxidation, Demulsibility Characteristics, Evaporation Loss, Oxidation Test, Oxidation Stability, Rotating Bomb Oxidation (RBOT), Rust Preventing Characteristics, Thin Film Oxidation Uptake, Tribology, Water Separability
FUEL TESTS
Bearing Compatibility, Cloud & Pour Points, Coking Tendency, Copper Strip Corrosion, Corrosion of Lead, Corrosivity/Oxidation, Demulsibility Characteristics, Evaporation Loss, Oxidation Test, Oxidation Stability, Rotating Bomb Oxidation (RBOT), Rust Preventing Characteristics, Thin Film, Oxidation Uptake, Tribology, Water Separability
LUBRICATING GREASE TESTS
Apparent Viscosity, Copper Strip Corrosion, Corrosion Preventive Properties, Dropping Point, Evaporation Loss, Grease Mobility, Leakage Tendencies, Life Performance, Low Temperature Torque, Oil Separation, Oxidation Stability, Particle Contamination, Penetration, Roll Stability, Tribology, Water Leaching, Water Spray Off, Water Washout Characteristics
GENERAL TESTS
Aniline Point, ASTM Color, Autoignition Temperature, Density and Relative Density, Distillation, Film Thickness, Flash Point, Kinematic Viscosity, Penetration, , Rust Protection, Salt in Crude, Sampling, Saybolt Color, Sediment Content, Sulfur Content, Thermometer Calibration, Unsulfonated Residue.
1. What's the warranty?
Normally 12 months
2.Does the power supply can customized?
YES ,if you need customized power supply,pls tell us when you put the order.
3.What's the production time?
Usually 20 days for production, some equipments need extra time to debug.
4.What's the Dlivery method ?
Light-weight cargo is usually by express , Air transport and sea shipping is acceptable (provide with safty packing)
5.What's the delivery time?
According to different method and country , express will be 6~15 days
6. How to install and operate?
According to each instruction manual which sent with equipment. ( We also provide after-sale technical support)
7.What's the payment term?
Usually we do 30%TT deposit ,70%TT balance before shipping.LC,Western Union,MoneyGram is acceptable.
