6mm sheet steel bending machine
Main features:
1 Streamlined design, advanced configuration, high precision and high efficiency
2 Derusting structure using grinding way, and spray with anticorrosive paint
3 The frame is entirely welded with steel plates, machined integrally to ensure precision by CNC horizontal boring machine
4 Top-drive design with working steady ,easy operating and safety.
5 In the dead center have confirmed when rolling function, to ensure that the workpiece precision
6 Sliding block large travel and high parallel tolerance on both sides.
7 Under the condition of the relevant national standards, bending Angle precision of plus or minus 30 '
8 A slow decline control function, the operator can better control the workpiece
9 The workbench deflection compensation function to ensure the precision of bending.
10Adopt servo motor drive control of the stopper, fast, stable and has high precision and low noise.
Technical data:
Tel us the thickness and the width, we can recommend you the suitable, contact me
Hydraulic bending machine wc67 series | ||||||||
Specification |
Pressure KN |
Worktable length mm |
Distance between uprights mm |
Throat Depth mm |
Stroke mm |
Opening height mm |
Main motor KW |
Weight |
WC67Y-40/2000 |
400 |
2500 |
1550 |
250 |
120 |
325 |
4 |
2600 |
WC67Y-40/2500 |
400 |
2500 |
2050 |
250 |
120 |
325 |
4 |
3000 |
WC67Y-63/2500 |
630 |
2500 |
2050 |
250 |
120 |
330 |
5.5 |
4200 |
WC67Y-63/3200 |
630 |
3200 |
2600 |
250 |
120 |
330 |
5.5 |
5100 |
WC67Y-80/2500 |
800 |
2500 |
2050 |
320 |
120 |
370 |
7.5 |
5800 |
WC67Y-80/3200 |
800 |
3200 |
2600 |
320 |
120 |
370 |
7.5 |
6100 |
WC67Y-100/2500 |
1000 |
2500 |
2050 |
320 |
120 |
380 |
7.5 |
6000 |
WC67Y-100/3200 |
1000 |
3200 |
2600 |
320 |
120 |
380 |
7.5 |
6600 |
WC67Y-100/4000 |
1000 |
4000 |
3200 |
320 |
120 |
380 |
7.5 |
8100 |
WC67Y-125/3200 |
1250 |
3200 |
2600 |
320 |
120 |
380 |
7.5 |
7000 |
remarks: ESTUN E10,E21,E200,DELEM DA41,DA52s,DA65 control system is optional
usage
Back gauge of the machine
Upper and lower Tool
Our workshop
CE certificate
(1)Spare parts:common tool with wear parts
(2)Shippment:Nominal package:20GP, 40GP,40HQ,40OT
(3)Delivery time:15-30days
(4)Payment terms:TT,30% in advance, the balance before shipment
(5)CE certificate
Skype: ntxwxtt Tel:0086-13584719466
