Specifications
hot sale vga to hdmi converter(convertor)Support video input : VGA analog
Support audio input : R/L analog
1280x1024
Hot sale vga to hdmi converter(convertor)
Support video input : VGA analog
Support audio input : R/L analog
1280x1024
The HDCVGA0101 Converter use a single VGA+R/L source,accessing to single HDMI1.1sink.The Converter allows one VGA+R/L device to be converted easily to one HDMI1.1 monitor or projector.
FEATURES
lOne VGA+R/L input signal convert to one HDMI sink devices
lSupport video input : VGA analog
lSupport audio input : R/L analog
lHDMI output : Support up to 1280x1024, same format as input
lSupport CEC
lLED indication: when source or sink is working, LED relative to is light.
lSupport output up to 20metres AWG26 cable length
lNo loss of quality
lInstalls in minutes
lNeed DC5V/1A power supply
SPECIFICATIONS: HDCVGA0101
| VGA Input | Support up to SXGA/SGA/UGA(50/60/75HZ) |
| Audio Input | R/L Analog |
| HDMI resolution | Support up to 1280x1024, same format as input |
| Max transmission bandwidth | 5.1Gbps |
| Input Video signal | 0.5~1.5Volts p-p |
| Output DDC signal | 5Volts p-p (TTL) |
| Output cable distance | ≤20m AWG26 HDMI standard cable |
| Max working current | 600mA |
| Power adapter format | Input:AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A |
| Operating Temperature range | (-15 to +55°C) |
| Operating Humidity range |
5 to 90%RH (No Condensation) |
| Dimension (L x W x H) | 90x70x33(mm) |
| Weight | 155g |
Notes:
Pls use the machine as the instruction listed to keep the long use lifetime of the machine.
- 1. The machine should be placed at the spot far from the Damp, High-Temperature, Dusty, Erosive, and oxidative environment.
- 2. All parts will be free from the strong shake, hit, fall.
- 3. Touching the power adaptor with the wet hands is prohibited.
- 4. Pls hold the power adaptor head and do not pull the power cord when cut off from the socket.
- 5. Pls turn the power off when the machine is not used for long time.
- 6. Pls do not open the cover and do not touch the inside parts.
- 7. Pls use the original factory power adaptor.
Before power on, pls check the connection line carefully. And make sure that all interfaces are normally connected. The common trouble shooting way shows below:
Serial NO |
Trouble Description |
Cause and Ways to deal with |
1 |
Non-Power-Connected |
1,Check if the power adaptor head is truly and correctly inserted the power socket. 2,Check the power switch if it is in on status. |
2 |
No Picture |
1,Pls to make sure that the TV is on and has been connected with the machine. 2,To check if the signal source is on and well connected.
3,Check the system connection quality. 4,Check if the line is all good quality. 5,Check the cable quality |
3 |
Obscure Picture |
1,To try again to connect the cable to be free from the unsuccessful connection. 2,HDMI Cable Quality |
