Specifications
The HDMI Repeater is mainly used for supporting the HDMI Signal long transmitting distance by amplifying the HDMI signal.
Features:
1. It can buffer and amplifier the signal.
2. 26 AWG HDMI Cable up to 30M.
3. Video Input Support: 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i.
4. Video Output Support: 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i.
5. No Loss of Signal Quality.
6. Easy Operation.
Specifications:
HDMI Connector…..………………….............……..………………….....Type A 19Pins Female
HDMI Input…..………………….....………24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
HDMI Output…..…………….…....…….…24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
Max Transmission Rate…………………………………………………………….…… 165MHz
Max Transmission Bandwidth………………….……………….………….…………4.95Gbps
Input Video Signal ………….…………………………..…….……………………1.2 volts p-p
Output DDC Signal ……………………………………………………………… 5Volts p-p (TTL)
Operating Temperature range……..…………….……………………………… (-15 to +55°C)
Operating Humidity range………………………….….……..5 to 90%RH (No Condensation)
Size(L*W*H) ……………………………….………………………………..45X26X16.5 mm
Weight…..…………………………………………………………….………………..…………30g
