Specifications
1.One HDMI Input to One HDMI Output, One SPDIF Audio Output and 2 RCA R/L Stereo Audio Output2.HDMI Supports Full HD 1080P+3D
One HDMI Input to One HDMI Output, One SPDIF Audio Output and 2 RCA R/L Stereo AudioOutput
SPDIF Output Supports Upto 5.1CH Audio; RCA Analog L/R Output Supports 2CH PCM Stereo Audio
HDMI Supports Full HD 1080P + 3D; Best Quality and Compatibility in Product Category
HDCP and EDID Pass Through; Plug & Play
Audio Settings 3 options : 2CH for L/R or SPDIF stereo output; 5.1CH for SPDIF Oupout
The HD1TO1LR1 converter allows the HD Source connected to single HD Display and adds extra one L+R and SPDIF audio out port.
FEATURES
lOne HDMI input converted to one HDMI+ Audio (SPDIF+R/L)output
lOutput audio support: SPDIF+R/L analog Audio Output
lInput Resolution: up to 1080P(50/60Hz)
lHDMI to achieve the synchronization of audio signal separation. There are PASS /
2.0CH / 5.1CH three kinds of audio mode options
lLED indication: when source or sink is working, LED relative to is light.
lNo loss of quality
lInstalls in minutes
lNeed DC5V/1A power supply
SWITCH:Audio mode switch
PASS: HDMI pass mode. The audio and video from the HDMI output,
SPDIF and L/R no output..
2CH: 2 channel stereo mode. The HDMI / SPDIF and L/R output stereo audio.
5.1CH: 5.1 channel mode. The HDMI / SPDIF output 5.1 channel audio, L/R no
output.
