Specifications
Support CECOne HDMI input signal split to two HDMI sink devices
Support Full HD, Full 3D
Support 4Kx2K resolution
FEATURES
lOne HDMI 1.4a input signal split to two HDMI 1.4a sink devices
lSupport 3D
lSupport 4K*2K resolution
lSupport CEC
lSupport deep color 30bit, 36bit, 48bit
lSupport Blue-Ray 24/50/60fs/HD-DVD/xvYCC
lDigital audio format, as DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3
/DSD/HD(HBR)
lSupport signal retiming
lSupport input up to 15metres AWG26 HDMI standard cable length,
output up to 20metres AWG26 cable length
lNo loss of quality
lInstalls in minutes
lNeed DC5V/2A power supply
SPECIFICATIONS: HDSP0102N
HDMI version…………………………………………….……………………………….. HDMI 1.4a
HDMI resolution ………………………........24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
Support video color format ……………………………..……. 24bit/deep color 30bit,36bit, 48bit
Support audio format………DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD HD(HBR)
Max bandwidth………………………………………………………………………………..340MHz
Max baudrate……………….…….………………….……………………………………..10.2Gbps
Input/Output TMDS signal ………….…………………………..……......… 0.5~1.5Volts p-p(TTL)
Input/Output DDC signal ………………………………………………..………… 5Volts p-p (TTL)
Input cable distance..…... …………….…………………….≤15m AWG26 HDMI standard cable
Output cable distance…………………………………..…...≤20m AWG26 HDMI standard cable
Max working current……………………………………………………………………….....1000mA
Power adapter format..Input: ………………...AC (50HZ, 60HZ) :100V-240V; Output: DC5V/2A
Operating Temperature range……..…………….…………………………………… (-15 to +55°C)
Operating Humidity range………………………….….………….5 to 90%RH (No Condensation)
Dimension (L x W x H) ……………………………….………………….…………110X52X20(mm)
Weight…..………………………………………………………..…….…..………………………141g
