Help CenterBS-S1 Powerful Solution Pos Laser Barcode Scanner Tablet Pc Barcode Scanner
Related Products
-
BS-S2 Good Quality Barcode Reader With One Year WarrantyNegotiableMOQ: 20 Pieces -
BS-B3 Low Cost Auto Sense Function Metal Bracket High Speed 200 Scan/ Sec Handheld 1D Laser Barcode ScannerUS$ 1 - 20MOQ: 1 Piece
-
BS-S3 Low Cost Handheld 1D Laser Barcode Scanner With Auto Scan FunctionNegotiableMOQ: 20 Pieces
-
BS-W2 Handheld Outdoor Wireless Bluetooth Barcode ScannerNegotiableMOQ: 20 Pieces
-
BS-B4-1D Hand Free Omni-direction Laser Barcode ScannerNegotiableMOQ: 10 Pieces
Specifications
1.Laser Barcode Scanner2.Strong Durable Structur
3.Good configurations with 32bit CUP
4.High scanning speed 200 scan/sec
1D Handheld barcode scanner
Features:
1. Comfortable ergonomic Design
2. Strong Durable Structur
3. Good configurations with 32bit CUP
4. High scanning speed 200 scan/sec
5. Very Low Failure Rate
Specification:
Scan Type |
Bi-directional |
Auto Sense |
Time interval:0.3s |
Light Source |
650nm Visible Laser diode |
CPU |
32 Bit Arm High Speed CPU |
Scan Rate |
200 scan /second |
Interfaces |
RS232,KBW,USB(2m),USB Virtual Serial Port |
Trigger Mode |
Handheld, continuous |
Handheld/auto sense switching time |
6s |
Promoting Mode |
Buzzer & indicator lamp |
Scan Width |
30cm |
Printing contract |
>25% |
Resolution |
3.3mil |
Voltage |
5v/3.3v+/-10%x100mA,idle:10mA |
Bit error rate |
1/500million,1/2000million |
Scan angle |
Rotor angle±30° Inclination angle ±45°, Elevation angle ±60° |
Anti-inference |
industrial lighting or sun will not make any difference |
Induction Parameters |
continuous sense interval time : 0.3s s Manual and auto-sense convert time: 6s |
Depth of field |
3.3mil (15mm-200mm) |
10 mil (10mm-400mm) | |
15.6mil(10mm-600mm) | |
35mil(10mm-1500mm) | |
Decode Capability |
UPC/EAN,UPC/EAN with supplemental,Codabar,UCC/EAN128,Code39,Code39Full ASCII,Code93,MSI,industrial/Intel Leaved 2 of 5,Code11,ISBN,ISSN,Chinapost, etc. |
Button life |
5000,000 times |
Relative humidity |
5%-95%(Non-condensation) |
Drop resistance capability |
1.5m fall to concrete |
Laser lifespan |
10000 hours |
Dimensions |
16.5x6.3x8.7mm |
Weight |
130g |
Related Regulations |
CE,FCC,Classl,CDRH CLASSI |
FAQ:
1.RS232 port scanner should with a power adaptor.
2.Packing default accessories not include bracket, the corresponding one with bracket is BS-B1.
3.The methods change key trigger mode to continue scan mode:
-Long push the trigger for 6 seconds.
-Scan the code “keytrigger” in use manual.
4. OEM Production:
-OEM your logo, MOQ is 300pcs with OEM charge free. If your order less than 300pcs, you can also pay OEM charge to make your logo. Exact cost depends on your requirements.
-OEM packing, MOQ is 1000pcs.
Last Update Time:2013-11-18
