2015 High Capacity Hammer Crusher for sale for salt
Introduction
Hammer crusher is suitable for mid-hard and light erosive materials, whose pressure resistance strength is no more than 100Mpa and humidity lower than 15%, such as coal, salt, chalk, gypsum, blocks, limestone, etc.
Working principle
Hammer crusher mainly consists of frame, rotor, trapezoidal iron plate, bar grate, etc. And the frame
consists of the upper part and the lower part, which are made of welded cut armor plate, while other
parts are connected into one by bolts. High manganese steel liners are mounted in the frame and can
be replaced after wearing out.
There are several sets of hammers equipped on the main shaft of the hammer crusher in regular
distribution. They constitute the rotor with dial and hammer shaft. Driven by the motor and V-belt,
the main shaft rotate with rotors. And the rotors spread to the surrounding extensions under the
centrifugal force brought from rotating.
So when big materials fall into the crushing cavity of hammer crusher, they will be broken into
pieces by high speed rotors. The qualified materials after crushing will be discharged from the
gap of grate at the bottom, while those unqualified ones will still stay in the crushing part and
then discharged when they reach the acceptable size after repeated actions of hammers and
trapezoidal iron plates.
Features
1.Hammer crusher has compact structure and reasonable layout.
2.It is convenient to install, and easy to operate and maintain.
3. It can crush large, medium and small sized stones, and has high reduction ratio.
The crushing machine is quite suitable for use in cement plants.
Technical Parameters
Heavy Mode
Type |
Rotor Diameter×length (mm) |
Mouse size W×l (mm) |
Feeding size ( mm) |
Capacity (t/h) |
Motor power ( KW) |
Theoretical weight |
Dimensions L*w*H mm |
PCZ1308 |
1310×790 |
850×800 |
≤600 |
100-160 |
132 |
11.2 |
2818×2100×2390 |
PCZ1510 |
1500×950 |
1000×900 |
≤700 |
160-210 |
132×2 |
17.1 |
3260×2414×2750 |
PCZ1512 |
1500×1160 |
1200×900 |
≤750 |
250-320 |
160×2 |
18.9 |
3260×2624×2750 |
PCZ1615 |
1650×1452 |
1500×1200 |
≤1000 |
360-420 |
200×2 |
28 |
3456×2915×3185 |
Standard Mode:
|
Mode |
Rotor diameter(mm) |
Specification Width*length(mm) |
Feeding particle diameter(mm) |
Output Capacity (t/h) |
Power kw |
Weight (t) |
Dimension (mm) |
PC-0706 |
700750 |
618*510 |
≤400 |
50-70 |
75 |
3.2 |
1950*1340*1480 |
PC-0808 |
800*750 |
780*610 |
≤500 |
80-100 |
132 |
5.3 |
2280*1790*1670 |
PC-0910 |
900*1000 |
1070*750 |
≤600 |
150-200 |
110*2 |
9.8 |
2600*2200*1940 |
PC-1012 |
1000*1180 |
1255*810 |
≤650 |
250-300 |
132*2 |
13.2 |
2800*2310*2210 |
PC-1213 |
1200*1280 |
1350*900 |
≤750 |
300-350 |
160*2 |
17.1 |
2970*2580*2510 |
After sale:
1.Installation,Debugging.
Provide installation files, technical data and related soft copies or videos etc to ensure customer
could install and debug by themselves.
2.warranty
The provider guarantee the vibrating screen could meet production technical standard and
performance requirements indicated in the contract, 24 months for the machine after delivery ,
12 months for the motor after delivery.
3.Technical Support
Our company will make occasional call to find problems and solve them in time.Provide technical support timely.
4.Response Time(24 hours)
Contact us through Telephone or Email, we will respond within 24 hour
