SPECIFICATIONS
Vertical Steam Wood Pellet Boiler
1.NominalCapacity: 0.5t/h
2.Work pressure: 0.1-0.7MPa
3.Good hydrodynamic features
Steam Wood Pellet Vertical Boiler
Features:
1.Compact structure, easy to install, small footprint, small investment.
2.The exhaust gas passes through the forced convection tube bundle, improving the efficiency of the boiler.
3.Because of multi-pass and multi-return, the dust can be removed naturally, so the boiler will work without induced draft fan and save energy.
Main Part of the technical parameters:
|
Name
Model
|
Rated evaporation (t/h) |
Working pressure (Mpa) |
Working temperature (°C) |
Size (m) |
HY0.5-0.4 |
0.5 |
0.4 |
151 |
1.2×3.5 |
HY0.7-0.4 |
0.7 |
0.4 |
151 |
1.4×3.8 |
HY1-0.4 |
1.0 |
0.4 |
151 |
1.6×4.6 |
HY0.5-0.7 |
0.5 |
0.7 |
170 |
1.2×3.7 |
HY0.7-0.7 |
0.7 |
0.7 |
170 |
1.4×4.0 |
HY1-0.7 |
1 |
0.7 |
170 |
1.6×4.6 |
Sepporting Equipment------
Presure Gage
Steam Header
Three Way Cock
Water Level Alarm
Water Pump
Since founded in 1990,Qingzhou Haiyu Industry has gained trust and friendship from almost every cornor of the globe ,especially from Africa,such as Kenya,Ghana,Cameroon,Ethiopia,Negeria,Sudan,Zambia,Uganda......
We care every client,we perchase perfection for every order,the satisfactory smile from African brothers is our best reward!
WE PROMISE
Satisfactory After-Sale Service
Professional Guidance,
High Quality !
Warmly Welcome To Visit Our Factory !
