Help CenterNail Pipe Clamp
Negotiable
MOQ: 3000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Usage:
Pipe Clamp
Material:
Metal
Structure:
Suspension Clamp
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Usage
Pipe Clamp
Material
Metal
Structure
Suspension Clamp
Standard or Nonstandard
Nonstandard
Specifications
Used for mounting of pipes to the walls ( vertical / horizontal ) , ceilings and floorsHanging type is by Nail
1.Used for mounting of pipes to the walls ( vertical / horizontal ) , ceilings and floors
2Hanging type is by Nail
3Easy and safe assembly through Philips combi side screws.
4.Electro galvanized for corrosion resistance (Plating thickness 8-10 micron).
| CODE | SIZE | D | S*B | M | STARDARD NAIL | PCS | carton size |
| 17B018 | 3/8" | 15-19 | 1.5*20 | M6*20 | M8*80 | 200 | 42*27*13 |
| 17B022 | 1/2" | 20-25 | 1.5*20 | M6*20 | M8*80 | 200 | 42*27*13 |
| 17B028 | 3/4" | 26-30 | 1.5*20 | M6*20 | M8*80 | 150 | 42*27*13 |
| 17B035 | 1" | 32-36 | 1.5*20 | M6*20 | M8*80 | 140 | 42*27*13 |
| 17B040 | 1-1/4" | 38-43 | 1.5*20 | M6*20 | M8*80 | 100 | 42*27*13 |
| 17B048 | 1-1/2" | 47-51 | 1.5*20 | M6*20 | M8*80 | 170 | 42*27*25 |
| 17B054 | - | 53-58 | 1.5*20 | M6*20 | M8*80 | 160 | 42*27*25 |
| 17B060 | 2" | 60-64 | 1.5*20 | M6*20 | M8*80 | 140 | 42*27*25 |
| 17B070 | - | 68-72 | 1.5*20 | M6*20 | M8*80 | 120 | 42*27*25 |
| 17B075 | 2-1/2" | 75-80 | 1.5*20 | M6*20 | M8*100 | 110 | 42*27*25 |
| 17B083 | 81-86 | 1.5*20 | M6*20 | M8*100 | 100 | 42*27*25 | |
| 17B090 | 3" | 87-92 | 1.5*20 | M6*20 | M8*100 | 90 | 42*27*25 |
| 17B100 | 3-1/2" | 99-105 | 2.0*20 | M6*20 | M8*100 | 80 | 42*27*25 |
| 17B110 | 107-112 | 2.0*20 | M6*20 | M8*100 | 60 | 42*27*25 | |
| 17B115 | 4" | 113-118 | 2.0*20 | M6*20 | M8*100 | 55 | 42*27*25 |
| 17B125 | 125-130 | 2.0*20 | M6*20 | M8*100 | 50 | 42*27*25 | |
| 17B150 | 5" | 138-142 | 2.0*20 | M6*20 | M8*100 | 40 | 42*27*25 |
| 17B160 | 6" | 159-166 | 2.0*20 | M6*20 | M8*100 | 25 | 42*27*25 |
| 17B220 | 8" | 215-220 | 2.0*20 | M6*20 | M8*100 | 15 | 42*27*25 |
