China CE Approved High Efficiency Bus Paint Spray Booth for Sale
Outside Size:(mm) |
9100(L)*4000(W)*3800(H) |
Color of wall panel |
White, orange, red and blue |
||
Inside Size:(mm) |
9000(L)*3900(W)*3400(H) |
Total Power:(kw) |
19.5;380V/3Phase/50Hz |
||
Cabin System |
Wall panel & |
The wall panel is EPS colorful steel skin panel,50mm thick,steel skin thickness 0.426mm, foam density 10Kg/m³, tongue&groove style,compound construction, anti-flame and heat-insulation. The roof panel is made by galvanized steel plate, thickness 0.8mm. |
|||
Front Door |
Folding door, 3 folds for 1 set,3000*3200mm(W×H),with safety glass ( thickness 5mm) windows. |
||||
Escape Door |
1 unit of 750*2000mm(W×H), with safety glass ( thickness 5mm) windows, |
||||
Basement |
Concret; 2 pits for ventilation, covered by galvanized steel grilles and fiberglass filter. |
||||
Air Circulation System |
Intake Fan(CE) |
2 sets of YDW-5.6S centrifugal fan,5.5kw motor each, max air capacity 30000m³/h. |
|||
Exhaust Fan(CE) |
1 set of YDW-5.6Mcentrifugal fan,7.5kw motor each, max.air capacity 21000m³/h. |
||||
Purification System |
Pre-filter,effectively capture the 10μm dust particles; |
||||
Heating System |
1set of Italy Riello G20 Diesel Burner,200000Kcal/h; 1piece of chimney, diameter 140mm; |
||||
Lighting System(CE) |
Ceiling Lights:10Units×3Pcs=30Pcs*18W, with electronic ballasts,power-coated light box. |
||||
MOQ |
1 set |
Package |
Wooden box/fumigation-free box/carton box |
Delivery terms |
FOB, EXW, CIF, CFR |
Delivery time |
Within 10 days after deposit |
Payment type |
T/T, L/C, Escrow |
Supply ability |
100 sets/month |
Port |
Qingdao |
CE certification
ISO9001 Certification
Package: Wooden box / fumigation-free box / carton box
Shipping: can transport to any port from Qingdao port
Advantages we have:
A. Experienced powder coating equipment supplier
B. Professional engineers team and sales department for your service
C. Alibaba golden supplier for 6 years, factory recognized by ‘CE ’ and ‘ISO 9001’
Benefit you get:
A. Stable quality – Coming from good materials and technic
B. Lower price – Not cheapest but the lowest at the same quality
C. Good service – Satisfactory service before and after sale
